Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 26" -
Travel Front 100mm -
Fork Fox
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Carbon MTB
Suspension Fork
Fox Float 100 Fit Remote 100mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore XT
Front Derailleur
Shimano Deore XT
Shift Levers
Shimano SLX
Cassette
Shimano HG81 11-36 10 spd
Crank
40/28
Bottom Bracket
FSA BB30
Chain
Shimano HG74
Pedals
N/A
Wheels
Front Hub
Easton EA70 XCT Wheelset
Rear Hub
Easton EA70 XCT Wheelset
Rims
Easton EA70 XCT Wheelset
Spokes
Easton EA70 XCT Wheelset
Tires
Maxxis Aspen 26x2.1 Kevlar
Brakes
Brakes
Shimano XT Disc
Brake Levers
Shimano XT Disc
Disk Rotors
Shimano XT 160mm
Cockpit
Stem
Easton EA70
Handlebar
Easton EC70
Grips
Kona Race Light LOG
Headset
FSA No.57E
Seat
Saddle
WTB Valcon Comp
Seatpost
Easton EC70
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 17" | 18" | 19" | 20" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.37 mm | 1.36 mm | 1.38 mm | 1.36 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 315 mm | 315 mm |
| Front Center | 665 mm | 675 mm | 690 mm | 690 mm | 705 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Stack | 565 mm | 575 mm | 585 mm | 595 mm | 600 mm |
| Reach | 410 mm | 420 mm | 430 mm | 430 mm | 440 mm |
| Top Tube Length | 590 mm | 600 mm | 615 mm | 625 mm | 640 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 405 mm | 430 mm | 455 mm | 485 mm | 510 mm |
| Head Tube Angle | 68 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 155 mm | 165 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1085 mm | 1095 mm | 1110 mm | 1110 mm | 1125 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 33 mm | 28 mm | 28 mm |
| Standover Height | 760 mm | 780 mm | 795 mm | 815 mm | 835 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
About this model
Kula Watt completes the Kona Kula model. 16 bikes variations carry this model name so far. You can easily view all of the Kona Kula bikes models from 2012, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Kula Watt components
Fork
The fork installed on this bike is the Fox model. The travel on this model is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the Kula Watt model has 26″ aluminum wheels. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona Kula Watt has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
