Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Apex -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
50cm
147cm - 170cm
52cm
157cm - 182cm
54cm
167cm - 188cm
56cm
175cm - 195cm
58cm
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted
Suspension Fork
Kona Verso Full Carbon Flat Mount Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
SRAM Apex
Front Derailleur
n/a
Shift Levers
SRAM Apex
Cassette
SRAM PG1130 11-42t 11spd
Crank
SRAM Apex, 40t X-Sync
Bottom Bracket
SRAM GXP 68mm
Chain
SRAM PC1110
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Formula 100x12mm
Rear Hub
Formula 142x12mm
Rims
WTB KOM Light Team i25 TCS 2.0
Spokes
Stainless Black 14g
Tires
WTB Riddler TCS 700x45c
Brakes
Brakes
TRP Spyre C
Brake Levers
SRAM Apex
Disk Rotors
TRP TR160 160mm
Cockpit
Stem
Kona Road
Handlebar
Kona Road
Grips
Kona Cork Tape
Headset
FSA No.57B
Seat
Saddle
WTB Volt
Seatpost
Kona Thumb w/Offset 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.53 mm | 1.57 mm | 1.61 mm | 1.67 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 288 mm | 288 mm | 290 mm |
| Front Center | 613 mm | 623 mm | 628 mm | 638 mm | 654 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 71 mm | 67 mm | 67 mm | 67 mm |
| Stack | 579 mm | 594 mm | 614 mm | 634 mm | 664 mm |
| Reach | 382 mm | 387 mm | 390 mm | 393 mm | 398 mm |
| Top Tube Length | 547 mm | 562 mm | 577 mm | 592 mm | 612 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 455 mm | 490 mm | 510 mm | 540 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 137 mm | 153 mm | 175 mm | 196.5 mm | 230 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1046 mm | 1056 mm | 1062 mm | 1072 mm | 1088 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 72 mm | 72 mm | 70 mm |
| Standover Height | 744 mm | 772 mm | 795 mm | 821 mm | 841 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 147 cm | 157 cm | 167 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 188 cm | 195 cm | 195 cm |
About this model
Libre AL belongs to the Kona Libre model. Kona released 15 bikes variations of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Kona Libre AL 2021 is the cheapest bike model and costs 1799$. Kona Libre CR/DL 2021 is the most expensive one and costs 3799$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Kona Libre AL price was 1799$. Doing a quick comparison, we notice that Libre AL price is 36.85% smaller than the average cost of a Gravel bike.
Libre AL components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When it comes to wheels, the Libre AL bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Libre AL has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Kona Libre AL bike has 5 sizes, in the range of 147 cm – 195 cm (4.82 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
