Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
50cm
147cm - 170cm
52cm
157cm - 182cm
54cm
167cm - 188cm
56cm
175cm - 195cm
58cm
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Carbon
Suspension Fork
Kona Verso Full Carbon Flat Mount Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano GRX 812
Front Derailleur
n/a
Shift Levers
Shimano GRX 600 w/ Integrated Dropper Lever
Cassette
Shimano SLX 11-42t 11spd
Crank
Shimano GRX 600, 40t
Bottom Bracket
Shimano PF86
Chain
Shimano 105
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Easton EA 70AX 100x12mm
Rear Hub
Easton EA 70AX 142x12mm
Rims
Easton EA 70AX Wheelset
Spokes
Easton EA 70AX Wheelset
Tires
WTB Riddler TCS DUAL 700x45c
Brakes
Brakes
Shimano GRX 400
Brake Levers
Shimano GRX
Disk Rotors
Shimano RT54 160mm (centerlock)
Cockpit
Stem
Easton EA70
Handlebar
Easton EA70AX
Grips
Velo Shock-Proof Bar Tape
Headset
FSA No.42ACB
Seat
Saddle
WTB Volt
Seatpost
TranzX Dropper +RAD Internal 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.53 mm | 1.57 mm | 1.61 mm | 1.67 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 288 mm | 288 mm | 290 mm |
| Front Center | 613 mm | 623 mm | 628 mm | 638 mm | 654 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 71 mm | 67 mm | 67 mm | 67 mm |
| Stack | 579 mm | 594 mm | 614 mm | 634 mm | 664 mm |
| Reach | 382 mm | 387 mm | 390 mm | 393 mm | 398 mm |
| Top Tube Length | 547 mm | 562 mm | 576 mm | 592 mm | 612 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 455 mm | 490 mm | 510 mm | 540 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 137.3 mm | 153.2 mm | 175.4 mm | 196.5 mm | 230.4 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1046 mm | 1056 mm | 1062 mm | 1072 mm | 1088 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 72 mm | 72 mm | 70 mm |
| Standover Height | 762 mm | 786 mm | 807 mm | 834 mm | 854 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 147 cm | 157 cm | 167 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 188 cm | 195 cm | 195 cm |
About this model
Libre CR/DL completes the Kona Libre model. There are 15 bikes that carry this model name. You can easily view all of the Kona Libre bikes models from 2022, here.
Model range prices
Kona Libre 2022 is the most affordable bike of this model and has a price of 2099$. On the other hand, Kona Libre CR/DL 2022, is the most expensive and costs 3799$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3799$. Doing a quick comparison, we notice that Libre CR/DL price is 54.31% higher than the average cost of a Gravel bike.
Libre CR/DL components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The Libre CR/DL 2022 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Libre CR/DL comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 147 cm – 195 cm (4.82 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
