Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
54cm
167cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Carbon
Suspension Fork
Kona Verso Full Carbon Flat Mount Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
SRAM Force 1
Front Derailleur
n/a
Shift Levers
SRAM Force 1
Cassette
SRAM XG1150 10-42t 11spd
Crank
SRAM Force 1 X-Sync, 40t X-Sync
Bottom Bracket
SRAM GXP PF
Chain
SRAM PC1110
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Easton EA 70AX 100x12mm
Rear Hub
Easton EA 70AX 142x12mm
Rims
Easton EA 70AX Wheelset
Spokes
Easton EA 70AX Wheelset
Tires
WTB Riddler TCS 700x45c
Brakes
Brakes
SRAM Force 1 Flat Mount
Brake Levers
SRAM Force 1 HRD
Disk Rotors
SRAM Centerline 160mm
Cockpit
Stem
Kona Road
Handlebar
Kona Road
Grips
Kona Cork Tape
Headset
FSA No.42ACB
Seat
Saddle
WTB SL8 Pro
Seatpost
Kona Thumb w/Offset 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 49cm | 51cm | 54cm | 55cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.53 mm | 1.57 mm | 1.61 mm | 1.67 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 288 mm | 288 mm | 290 mm |
| Front Center | 613 mm | 623 mm | 628 mm | 638 mm | 654 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 71 mm | 67 mm | 67 mm | 67 mm |
| Stack | 579 mm | 594 mm | 614 mm | 634 mm | 664 mm |
| Reach | 382 mm | 387 mm | 390 mm | 393 mm | 398 mm |
| Top Tube Length | 547 mm | 562 mm | 576 mm | 592 mm | 612 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 455 mm | 490 mm | 510 mm | 540 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 137.3 mm | 153.2 mm | 175.4 mm | 196.5 mm | 230.4 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1046 mm | 1056 mm | 1062 mm | 1072 mm | 1088 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 72 mm | 72 mm | 70 mm |
| Standover Height | 762 mm | 786 mm | 807 mm | 834 mm | 854 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Libre DL completes the Kona Libre model. There are 15 bikes that carry this model name. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Kona Libre 2019 is the cheapest bike model and costs 2999$. Kona Libre DL 2019 is the most expensive one and costs 3999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Kona Libre DL price was 3999$. Comparing this to the average Gravel bike price, we see that the price is 62.43% higher.
Libre DL components
Fork material
Libre DL has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the Libre DL bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
