Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
56cm
175cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Carbon
Suspension Fork
Kona Full Carbon CX Race
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano 105
Shift Levers
Shimano Ultegra
Cassette
Shimano Ultegra 11-28t 10 spd
Crank
36/46t
Bottom Bracket
FSA BB30
Chain
Shimano 105
Pedals
N/A
Wheels
Front Hub
Shimano Ultegra Tubeless Wheelset
Rear Hub
Shimano Ultegra Tubeless Wheelset
Rims
Shimano Ultegra Tubeless Wheelset
Spokes
Shimano Ultegra Tubeless Wheelset
Tires
Maxxis Mud Wrestler 700x33C
Brakes
Brakes
Avid Shorty Ultimate
Brake Levers
Shimano Ultegra
Disk Rotors
N/A
Cockpit
Stem
Easton EA70
Handlebar
Easton EA70
Grips
Kona Cork Tape
Headset
FSA No.57-CX
Seat
Saddle
WTB Volt Team
Seatpost
Easton EA70
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 53cm | 56cm | 59cm | 61cm | 63cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.4 mm | 1.43 mm | 1.47 mm | 1.43 mm | 1.46 mm |
| Bottom Bracket Height | 288 mm | 288 mm | 288 mm | 288 mm | 288 mm | 288 mm |
| Front Center | 595 mm | 603 mm | 613 mm | 623 mm | 640 mm | 648 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 68 mm | 61 mm | 60 mm | 60 mm | 60 mm | 59 mm |
| Stack | 530 mm | 557 mm | 576 mm | 595 mm | 606 mm | 620 mm |
| Reach | 390 mm | 398 mm | 402 mm | 406 mm | 423 mm | 426 mm |
| Top Tube Length | 540 mm | 555 mm | 570 mm | 585 mm | 610 mm | 620 mm |
| Seat Tube Angle | 74.2 ° | 74.2 ° | 73.7 ° | 73.2 ° | 72.7 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 530 mm | 560 mm | 590 mm | 610 mm | 630 mm |
| Head Tube Angle | 71.2 ° | 72.2 ° | 72.2 ° | 72.2 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 110 mm | 135 mm | 155 mm | 175 mm | 185 mm | 200 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1017 mm | 1025 mm | 1036 mm | 1046 mm | 1062 mm | 1070 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm |
| Standover Height | 766 mm | 800 mm | 818 mm | 836 mm | 850 mm | 878 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
MAJOR JAKE belongs to the Kona Jake model. Kona launched 47 bikes of this model so far. Take a sneak peek at all Kona Jake bikes models from 2013, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Cyclocross bikes average price
If you want an acceptable Cyclocross bike you should know that the average price is 2012$. However, this doesn’t mean that if you spend less money on a Cyclocross bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
MAJOR JAKE components
Fork material
MAJOR JAKE has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When leaving the production line, the MAJOR JAKE model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona MAJOR JAKE is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
