Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
56cm
175cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Carbon
Suspension Fork
Kona Full Carbon CX Race Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano 105
Shift Levers
Shimano 105
Cassette
Shimano 105 11-28t 11spd
Crank
36/46t
Bottom Bracket
FSA Press Fit 30
Chain
KMC X11
Pedals
n/a
Wheels
Front Hub
Stan's Iron Cross Team Tubeless Wheelset
Rear Hub
Stan's Iron Cross Team Tubeless Wheelset
Rims
Stan's Iron Cross Team Tubeless Wheelset
Spokes
Stan's Iron Cross Team Tubeless Wheelset
Tires
Challenge Grifo Plus 700x32c 60TPI Folding
Brakes
Brakes
Hayes CX Expert
Brake Levers
Shimano 105Shimano 105
Disk Rotors
Hayes L Series 160mm
Cockpit
Stem
Kona XC/Road Deluxe
Handlebar
Kona Road
Grips
Kona Cork Tape
Headset
FSA No.57B
Seat
Saddle
WTB Volt CompWTB Volt Comp
Seatpost
Kona Thumb w/Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 53cm | 56cm | 59cm | 61cm | 63cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.4 mm | 1.43 mm | 1.47 mm | 1.43 mm | 1.46 mm |
| Bottom Bracket Height | 282 mm | 282 mm | 282 mm | 282 mm | 282 mm | 282 mm |
| Front Center | 595 mm | 603 mm | 613 mm | 623 mm | 640 mm | 648 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 68 mm | 61 mm | 61 mm | 60 mm | 60 mm | 64 mm |
| Stack | 530 mm | 557 mm | 576 mm | 595 mm | 606 mm | 620 mm |
| Reach | 390 mm | 398 mm | 402 mm | 406 mm | 423 mm | 426 mm |
| Top Tube Length | 540 mm | 555 mm | 570 mm | 585 mm | 610 mm | 620 mm |
| Seat Tube Angle | 74.2 ° | 74.2 ° | 73.7 ° | 73.2 ° | 72.7 ° | 72.2 ° |
| Seat Tube Length | 490 mm | 530 mm | 560 mm | 590 mm | 610 mm | 630 mm |
| Head Tube Angle | 71.2 ° | 72.2 ° | 72.2 ° | 72.2 ° | 72.5 ° | 72.2 ° |
| Head Tube Length | 110 mm | 135 mm | 155 mm | 175 mm | 185 mm | 200 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1017 mm | 1025 mm | 1035 mm | 1046 mm | 1062 mm | 1070 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm |
| Standover Height | 775 mm | 790 mm | 810 mm | 830 mm | 840 mm | 880 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
MAJOR JAKE is a Kona Jake model. 47 bikes variations carry this model name so far. You can easily view all of the Kona Jake bikes models from 2015, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Cyclocross bikes
Our math shows that the average cost of a dependable Cyclocross bike is 2012$. However, this doesn’t mean that if you spend less money on a Cyclocross bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork material
MAJOR JAKE has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The MAJOR JAKE 2015 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
