Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 190mm -
Travel Rear 195mm -
Fork RockShox BoXXer
-
Groupset GX, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
157cm - 182cm
LG
175cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona DH Carbon w/ 6061 Aluminum Chain Stays 195mm Travel (205mm in 27.5)
Suspension Fork
RockShox Boxxer WC Charger 2 DebonAir 190mm
Rear Shock
RockShox Super Deluxe Coil RC Trunnion
Drivetrain
Rear Derailleur
SRAM GX DH
Front Derailleur
n/a
Shift Levers
SRAM GX DH
Cassette
SRAM PG720 11-25t 7spd
Crank
SRAM Descendant DH, 36t
Bottom Bracket
SRAM GXP PF
Chain
SRAM PC1110
Chain Guide
MRP SXg
Pedals
n/a
Wheels
Front Hub
Formula 110x20mm
Rear Hub
Formula 157x12mm
Rims
Mavic EX630
Spokes
Stainless Black 14g
Tires
Maxxis Minion DHF DH TR 3C 29x2.5"
Brakes
Brakes
SRAM Code R
Brake Levers
SRAM Code R
Disk Rotors
SRAM Centerline 200mm
Cockpit
Stem
RaceFace Atlas DM 35mm
Handlebar
RaceFace Atlas 35mm
Grips
Kona Key Grip
Headset
FSA Orbit C No.8 ACB
Seat
Saddle
WTB Volt Race
Seatpost
Kona OB 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Bottom Bracket Height | 355 mm | 353 mm |
| Front Center | 806 mm | 815 mm |
| Rake | 56 mm | 56 mm |
| Stack | 619 mm | 624 mm |
| Top Tube Length | 554 mm | 566 mm |
| Seat Tube Angle | 79.5 ° | 79.5 ° |
| Seat Tube Length | 440 mm | 440 mm |
| Head Tube Angle | 62 ° | 62 ° |
| Head Tube Length | 117 mm | 122 mm |
| Chainstay Length | 431 mm | 431 mm |
| Wheelbase | 1239 mm | 1247 mm |
| Bottom Bracket Drop | 20 mm | 22 mm |
| Standover Height | 764 mm | 766 mm |
| Wheels | 29" | 29" |
| Rider Min Height | 157 cm | 175 cm |
| Rider Max Height | 182 cm | 195 cm |
About this model
Operator CR completes the Kona Operator model. Kona launched 17 bikes of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
The most economical model, the Kona Operator 2019 has a starting price of 3699$. Kona Operator CR 2019 on the other hand is the most expensive at 5999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Downhill bikes
Our math shows that the average cost of a dependable Downhill bike is 3391$. However, even if your budget is less than the average, you might still be able to get a top-quality Downhill bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2019 and its price was 5999$. Comparing the average cost of a Downhill bike to this one, you will see that Operator CR price is 76.91% more expensive.
Operator CR components
Fork
The fork installed on this bike is the RockShox BoXXer model. The travel on this model is 190mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
As for the rear shock, this bike has the RockShox Super Deluxe Coil RC Trunnion model, with a travel of 195mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When leaving the production line, the Operator CR model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Operator CR comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Operator CR comes in 2 sizes, that range from 157 cm – 195 cm (5.15 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
