Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 111mm -
Fork RockShox Revelation RC
-
Groupset X9 -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted 111mm Travel
Suspension Fork
RockShox Revelation RL Solo Air 120mm QR15 Tapered
Rear Shock
RockShox Monarch RT
Drivetrain
Rear Derailleur
SRAM X9 Type 2
Front Derailleur
The Hive LS1+ No Taco
Shift Levers
SRAM X9
Cassette
SRAM PG1070 11-36t 10 spd
Crank
34t
Bottom Bracket
Shimano Press Fit 92
Chain
KMC X10
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Shimano SLX QR15
Rear Hub
Shimano SLX 142x12mm
Rims
WTB ST i23 TCS
Spokes
Sandvik Stainless 14g
Tires
Maxxis Ardent 29x2.4" EXO
Brakes
Brakes
Shimano SLX
Brake Levers
Shimano SLX
Disk Rotors
Shimano Deore 180mm (centerlock)
Cockpit
Stem
Kona 40mm
Handlebar
Kona XC/BC Riser
Grips
Kona S-LOG
Headset
FSA Orbit 1.5 ZS No.57
Seat
Saddle
WTB Volt Sport SE
Seatpost
KS Lev Integra
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.39 mm | 1.34 mm | 1.28 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 696 mm | 717 mm | 746 mm | 772 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 102 mm | 102 mm | 102 mm | 102 mm |
| Stack | 608 mm | 613 mm | 622 mm | 626 mm |
| Reach | 421 mm | 440 mm | 465 mm | 490 mm |
| Top Tube Length | 590 mm | 610 mm | 639 mm | 666 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 405 mm | 405 mm | 450 mm | 465 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1129 mm | 1150 mm | 1178 mm | 1205 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 665 mm | 665 mm | 672 mm | 672 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
PROCESS 111 is part of the Kona Process 111 model. Kona released 6 bikes variations of this model so far. You can easily view all of the Kona Process 111 bikes models from 2014, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
This bike has the RockShox Revelation RC fork installed. The fork’s travel is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this bike has the RockShox Monarch RT model, with a travel of 111mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When leaving the production line, the PROCESS 111 model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Kona PROCESS 111 includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
