Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 111mm -
Fork RockShox Revelation RC
-
Groupset XX1 -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted 111mm Travel
Suspension Fork
RockShox Revelation RTC3 Solo Air 120mm QR15 Tapered
Rear Shock
RockShox Monarch RT3
Drivetrain
Rear Derailleur
SRAM XX1 Type 2
Front Derailleur
n/a
Shift Levers
SRAM XX1
Cassette
SRAM XX1 11-42t 11 spd
Crank
34t
Bottom Bracket
SRAM Press Fit 92
Chain
SRAM XX1
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Hope Pro 2 QR15
Rear Hub
Hope Pro 2 142x12mm
Rims
Stan's Flow EX
Spokes
DT Competition Butted Black
Tires
Maxxis Ardent 29x2.4" EXO
Brakes
Brakes
Avid XO Trail
Brake Levers
Avid XO Trail
Disk Rotors
Avid HS1 180mm
Cockpit
Stem
Kona 40mm
Handlebar
RaceFace Atlast FR
Grips
Kona S-LOG
Headset
FSA Orbit 1.5 ZS No.57
Seat
Saddle
WTB Volt Race
Seatpost
KS Lev Integra
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.39 mm | 1.34 mm | 1.28 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 696 mm | 717 mm | 746 mm | 772 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 102 mm | 102 mm | 102 mm | 102 mm |
| Stack | 608 mm | 613 mm | 622 mm | 626 mm |
| Reach | 421 mm | 440 mm | 465 mm | 490 mm |
| Top Tube Length | 590 mm | 610 mm | 639 mm | 666 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 405 mm | 405 mm | 450 mm | 465 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1129 mm | 1150 mm | 1178 mm | 1205 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 665 mm | 665 mm | 672 mm | 672 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
PROCESS 111 DL is part of the Kona Process 111 model. Kona launched 6 bikes of this model so far. You can get a glimpse at all models from 2014, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The fork installed on this bike is the RockShox Revelation RC model. The travel on this model is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The PROCESS 111 DL has a rear shock with a travel of 111mm. The model RockShox Monarch RT3 is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The PROCESS 111 DL 2014 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The PROCESS 111 DL comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Kona PROCESS 111 DL bike has 4 sizes, in the range of 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the PROCESS 111 DL. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
