Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 111mm -
Fork RockShox Pike RCT3
-
Groupset X01 -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted 111mm Travel
Suspension Fork
RockShox Pike RCT3 120mm QR15 Tapered
Rear Shock
RockShox Monarch RCT3
Drivetrain
Rear Derailleur
SRAM XO1
Front Derailleur
n/a
Shift Levers
SRAM XO1
Cassette
SRAM XG1195 10-42t 11spd
Crank
32t
Bottom Bracket
RaceFace Press Fit 92
Chain
KMC X11
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Novatech 15mm
Rear Hub
Novatech 142x12mm
Rims
WTB Asym i29 TCS
Spokes
Sandvik Stainless 14g Black
Tires
Maxxis Minion DHF EXO DUAL TR 29x2.3"
Brakes
Brakes
Shimano XT
Brake Levers
Shimano XT
Disk Rotors
Shimano XT 180mm (centerlock)
Cockpit
Stem
Kona XC/BC 35
Handlebar
RaceFace Atlas
Grips
ODI Ruffian MX
Headset
FSA Orbit 1.5 ZS No.57
Seat
Saddle
WTB SL8 Team
Seatpost
KS Lev Integra
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.39 mm | 1.34 mm | 1.28 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 696 mm | 717 mm | 746 mm | 772 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 102 mm | 102 mm | 102 mm | 102 mm |
| Stack | 609 mm | 614 mm | 623 mm | 627 mm |
| Reach | 422 mm | 441 mm | 466 mm | 491 mm |
| Top Tube Length | 591 mm | 611 mm | 640 mm | 667 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 406 mm | 406 mm | 450 mm | 465 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm | 120 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1130 mm | 1151 mm | 1179 mm | 1206 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 666 mm | 666 mm | 673 mm | 673 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
Process 111 DL is part of the Kona Process 111 model. There are 6 bikes that carry this model name. Check out the entire range from 2016 of this model, by clicking this link.
Model range prices
The most economical model, the Kona Process 111 2016 has a starting price of 4099$. Kona Process 111 DL 2016 on the other hand is the most expensive at 5199$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Kona released this model in 2016, its price was 5199$. Comparing this to the average Crosscountry bike price, we see that the price is 172.91% higher.
Overview of components
Fork
The Process 111 DL comes factory-installed with the RockShox Pike RCT3 fork. This has a travel range of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the RockShox Monarch RCT3 rear shock model, which has a travel of 111mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The wheels on Process 111 DL are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Process 111 DL comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 152 cm – 195 cm (4.99 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
The Kona model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
