Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 134mm -
Fork RockShox Revelation RC
-
Groupset X1 -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 154cm
SM
152cm - 170cm
MD
157cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted 134mm Travel
Suspension Fork
RockShox Revelation RL Solo Air 140mm QR15 Tapered
Rear Shock
RockShox Monarch RT
Drivetrain
Rear Derailleur
SRAM X1
Front Derailleur
n/a
Shift Levers
SRAM X1
Cassette
SRAM XG1180 10-42t 11spd
Crank
30t
Bottom Bracket
SRAM Press Fit GXP 92
Chain
KMC X11
Pedals
n/a
Wheels
Front Hub
Novatech QR15
Rear Hub
Novatech 142x12mm
Rims
WTB KOM i23 TCS
Spokes
Stainless 14g Black
Tires
Maxxis Ardent EXO TR 27.5x2.25"
Brakes
Brakes
Shimano Deore
Brake Levers
Shimano Deore
Disk Rotors
Shimano 180mm (centerlock)
Cockpit
Stem
RaceFace Atlas
Handlebar
RaceFace Turbine
Grips
Kona S-LOG
Headset
FSA Orbit 1.5 ZS No.57
Seat
Saddle
WTB Volt Sport 250
Seatpost
KS Lev DX
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.44 mm | 1.39 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm |
| Front Center | 664 mm | 697 mm | 715 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 97 mm | 97 mm | 102 mm |
| Stack | 574 mm | 592 mm | 601 mm |
| Reach | 386 mm | 412 mm | 431 mm |
| Top Tube Length | 545 mm | 578 mm | 596 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 345 mm | 405 mm | 405 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 115 mm | 125 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1086 mm | 1119 mm | 1137 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm |
| Standover Height | 646 mm | 646 mm | 646 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 147 cm | 152 cm | 157 cm |
| Rider Max Height | 154 cm | 170 cm | 182 cm |
About this model
PROCESS 134 SE completes the Kona Process 134 model. 38 bikes variations carry this model name so far. Check out the entire range from 2015 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
The fork installed on this bike is the RockShox Revelation RC model. The travel on this model is 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The PROCESS 134 SE has a rear shock with a travel of 134mm. The model RockShox Monarch RT is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When it comes to wheels, the PROCESS 134 SE bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 147 cm – 182 cm (4.82 ft – 5.97 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the PROCESS 134 SE. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
