Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 153mm -
Fork Fox Performance Float 36
-
Groupset GX, GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona DH Carbon w/ 6061 Aluminum Chain Stays 153mm Travel
Suspension Fork
Fox Float 36 Performance 160mm Tapered 110mm Spacing
Rear Shock
Fox Float DPX2 Performance Elite Compression Adjust Trunnion
Drivetrain
Rear Derailleur
SRAM GX-Eagle
Front Derailleur
n/a
Shift Levers
SRAM GX-Eagle
Cassette
SRAM GX-Eagle 10-50t 12spd
Crank
SRAM GX Eagle DUB, 32t X-Sync Eagle
Bottom Bracket
SRAM DUB PF92
Chain
SRAM NX-Eagle
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
DT Swiss 370 110x15mm
Rear Hub
DT Swiss 370 148x12mm
Rims
WTB KOM Trail i30 TCS
Spokes
Stainless Black 14g
Tires
Maxxis Assegai EXO TR 3C 29x2.5" WT
Brakes
Brakes
SRAM Guide R
Brake Levers
SRAM Guide R
Disk Rotors
SRAM Centerline 200mm
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35
Grips
Kona Key Grip
Headset
FSA Orbit 1.5 E ZS
Seat
Saddle
WTB Volt Pro
Seatpost
RockShox Reverb w/1x Remote Lever 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.3 mm | 1.23 mm |
| Bottom Bracket Height | 346 mm | 346 mm | 346 mm |
| Front Center | 766 mm | 795 mm | 834 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 111 mm | 111 mm | 110 mm |
| Stack | 618 mm | 627 mm | 636 mm |
| Reach | 456 mm | 481 mm | 516 mm |
| Top Tube Length | 609 mm | 638 mm | 677 mm |
| Seat Tube Angle | 76 ° | 75.8 ° | 75.7 ° |
| Seat Tube Length | 406 mm | 450 mm | 482 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1195 mm | 1224 mm | 1264 mm |
| Bottom Bracket Drop | 29 mm | 29 mm | 29 mm |
| Standover Height | 708 mm | 708 mm | 707 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 182 cm | 195 cm | 195 cm |
About this model
Process 153 CR 29 completes the Kona Process 153 model. Kona launched 42 bikes of this model so far. Take a sneak peek at all Kona Process 153 bikes models from 2020, by clicking here.
Model range prices
Kona Process 153 27.5 2020 is the most affordable bike of this model and has a price of 2799$. On the other hand, Kona Process 153 CR/DL 29 TEAM REPLICA 2020, is the most expensive and costs 7999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro bikes
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4699$. Comparing the average cost of an Enduro bike to this one, you will see that Process 153 CR 29 price is 30.56% more expensive.
Overview of components
Fork
Kona Process 153 CR 29 2020 bike is equipped with the Fox Performance Float 36 fork, and has 160mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the Fox Float DPX2 Performance Elite Compression Adjust Trunnion rear shock model, which has a travel of 153mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When leaving the production line, the Process 153 CR 29 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The Process 153 CR 29 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Process 153 CR 29 comes in 3 sizes, that range from 157 cm – 195 cm (5.15 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Kona Process 153 CR 29 includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
