Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 153mm -
Fork RockShox Pike RCT3
-
Groupset X01 -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted 153mm Travel
Suspension Fork
RockShox Pike RCT3 Solo Air 160mm QR15 Tapered
Rear Shock
RockShox Monarch Plus RC3
Drivetrain
Rear Derailleur
SRAM XO1
Front Derailleur
n/a
Shift Levers
SRAM XO1
Cassette
SRAM XG1195 10-42t 11spd
Crank
32t, X-Sync w/Guard
Bottom Bracket
SRAM Press Fit GXP 92
Chain
KMC X11
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Novatech QR15
Rear Hub
Novatech 142x12mm
Rims
WTB ASYM i35
Spokes
Sandvik Stainless 14g Black
Tires
Maxxis Minion DHF EXO 27.5x2.3"
Brakes
Brakes
Shimano XT
Brake Levers
Shimano XT
Disk Rotors
Shimano XT IceTech 203mm (centerlock)
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35 Riser
Grips
ODI Ruffian MX
Headset
FSA Orbit 1.5 ZS No.57
Seat
Saddle
WTB Volt Team / Volt Team 250
Seatpost
KS Lev Integra
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.37 mm | 1.31 mm | 1.26 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm | 345 mm |
| Front Center | 713 mm | 736 mm | 765 mm | 792 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 109 mm | 109 mm | 108 mm | 109 mm |
| Stack | 592 mm | 601 mm | 610 mm | 615 mm |
| Reach | 421 mm | 440 mm | 465 mm | 490 mm |
| Top Tube Length | 583 mm | 606 mm | 634 mm | 661 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 405 mm | 405 mm | 450 mm | 465 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 130 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1143 mm | 1166 mm | 1195 mm | 1222 mm |
| Bottom Bracket Drop | 10 mm | 10 mm | 10 mm | 10 mm |
| Standover Height | 660 mm | 660 mm | 670 mm | 670 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
Process 153 DL completes the Kona Process 153 model. Kona released 42 bikes variations of this model so far. You can easily view all of the Kona Process 153 bikes models from 2016, here.
Model range prices
The most economical model, the Kona Process 153 2016 has a starting price of 3599$. Kona Process 153 DL 2016 on the other hand is the most expensive at 4999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro bikes
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2016 for 4999$. Comparing the average cost of an Enduro bike to this one, you will see that Process 153 DL price is 38.9% more expensive.
Process 153 DL components
Fork
The RockShox Pike RCT3 is included from the factory. It has a travel distance of 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Kona Process 153 DL bike has the RockShox Monarch Plus RC3 model installed, and has a travel of 153mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The Process 153 DL 2016 bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona Process 153 DL has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
