Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" / 29" -
Travel Front 170mm -
Travel Rear 161mm -
Fork RockShox ZEB Ultimate
-
Groupset X01, GX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Carbon 161mm Travel
Suspension Fork
RockShox Zeb Ultimate RC2 charger 2.1 DebonAir 170mm Tapered 110mm Spacing
Rear Shock
RockShox Super Deluxe Ultimate Trunnion
Drivetrain
Rear Derailleur
SRAM X01-Eagle
Front Derailleur
n/a
Shift Levers
SRAM X01-Eagle
Cassette
SRAM X01-Eagle 10-52t 12spd
Crank
SRAM GX-Eagle Carbon DUB, 32t X-Sync Eagle
Bottom Bracket
SRAM DUB PF92
Chain
SRAM GX-Eagle
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
DT Swiss 350 110x15mm
Rear Hub
DT Swiss 350 148x12mm
Rims
WTB KOM Trail i30 TCS
Spokes
Double Butted Spokes – 14/15/14g
Tires
Maxxis Minion DHR II EXO+ TR 3C 29x2.4" WT (27.5x2.4" WT size S)
Brakes
Brakes
SRAM Code RSC
Brake Levers
SRAM Code RSC
Disk Rotors
SRAM Centerline 200mm
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35
Grips
Kona Key Grip
Headset
FSA Orbit 1.5 EP ZS
Seat
Saddle
WTB Volt
Seatpost
Rock Shox Reverb w/1x Remote Lever 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.32 mm | 1.28 mm | 1.21 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm | 345 mm |
| Front Center | 779 mm | 804 mm | 834 mm | 874 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 136 mm | 140 mm | 140 mm | 140 mm |
| Stack | 612 mm | 612 mm | 622 mm | 632 mm |
| Reach | 437 mm | 462 mm | 487 mm | 522 mm |
| Top Tube Length | 566 mm | 591 mm | 620 mm | 659 mm |
| Seat Tube Angle | 78.2 ° | 78.2 ° | 78 ° | 77.9 ° |
| Seat Tube Length | 380 mm | 380 mm | 420 mm | 450 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 94 mm | 94 mm | 105 mm | 116 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1210 mm | 1235 mm | 1265 mm | 1305 mm |
| Bottom Bracket Drop | 20 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 687 mm | 697 mm | 707 mm | 717 mm |
| Wheels | 27" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
Model Overview
Process X DL is part of the Kona Process X model. There are 8 bikes that carry this model name. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Kona Process X 2021 is the most affordable bike of this model and has a price of 5199$. On the other hand, Kona Process X DL 2021, is the most expensive and costs 7199$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro bikes
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2021 for 7199$. Doing a quick comparison, we notice that Process X DL price is 100.03% more expensive than the average cost of an Enduro bike.
Process X DL components
Fork
The fork installed on this bike is the RockShox ZEB Ultimate model. The travel on this model is 170mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Kona Process X DL bike has the RockShox Super Deluxe Ultimate Trunnion model installed, and has a travel of 161mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When leaving the production line, the Process X DL model has 27.5″ aluminum wheels. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Kona Process X DL bike has 4 sizes, in the range of 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Kona Process X DL comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
