Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 132mm -
Fork RockShox Yari RC
-
Groupset NX, EX1 -
Suspension Full -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch PowerTube 500Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted 132mm Travel
Suspension Fork
RockShox Yari RC Motion Control DebonAir 150mm Tapered 110 Spacing
Rear Shock
RockShox Monarch Plus R Solo Air
Drivetrain
Rear Derailleur
SRAM NX
Front Derailleur
n/a
Shift Levers
SRAM NX
Cassette
SRAM PG1130 11-42t 11spd
Crank
SRAM EX1, 14t
Bottom Bracket
n/a
Chain
SRAM NX
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Formula 110x15mm
Rear Hub
Formula 148x12mm
Rims
WTB ST i40 TCS
Spokes
Stainless Black 14g
Tires
Maxxis Rekon EXO TR DUAL 27.5x2.8"
Brakes
Brakes
SRAM Guide RE
Brake Levers
SRAM Guide RE
Disk Rotors
SRAM Centerline 200mm
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35
Grips
Kona Key Grip
Headset
FSA No.57B
Seat
Saddle
WTB Volt Sport
Seatpost
Trans-X Dropper Internal 30.9mm
Motor & Battery
Motor
Bosch Performance Line CX 20MPH
Battery
Bosch PowerTube 500Wh
Remote
Bosch Purion
Charger
2A Compact Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.39 mm | 1.32 mm | 1.24 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm | 345 mm |
| Front Center | 753 mm | 778 mm | 803 mm | 842 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 104 mm | 104 mm | 104 mm | 102 mm |
| Stack | 629 mm | 629 mm | 629 mm | 638 mm |
| Reach | 428 mm | 453 mm | 478 mm | 513 mm |
| Top Tube Length | 607 mm | 632 mm | 657 mm | 695 mm |
| Seat Tube Angle | 74.3 ° | 74.3 ° | 74.3 ° | 74.2 ° |
| Seat Tube Length | 420 mm | 445 mm | 475 mm | 505 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 130 mm | 130 mm | 130 mm | 140 mm |
| Chainstay Length | 488 mm | 488 mm | 488 mm | 488 mm |
| Wheelbase | 1240 mm | 1265 mm | 1290 mm | 1330 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 793 mm | 781 mm | 773 mm | 793 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
Remote CTRL is part of the Kona E Remote model. 16 e-bikes variations carry this model name so far. You can easily view all of the Kona E Remote e-bikes models from 2020, here.
Model range prices
Kona Remote 2020 is the most economical model, with a starting price of 3799$. Kona Remote 160 2020 on the other hand costs 5999$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail e-bikes average price
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
When Kona released this model in 2020, its price was 4999$. Comparing the average cost of a Trail e-bike to this one, you will see that Remote CTRL price is 48.56% higher.
Overview of components
Fork
This e-bike has the RockShox Yari RC fork installed. The fork’s travel is 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
As for the rear shock, this e-bike has the RockShox Monarch Plus R Solo Air model, with a travel of 132mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The Remote CTRL 2020 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona Remote CTRL is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Kona Remote CTRL e-bike has 4 sizes, in the range of 152 cm – 195 cm (4.99 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
