Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset X9, Apex -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
56cm
175cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Cromoly Butted
Suspension Fork
Kona Project Two Touring
Rear Shock
n/a
Drivetrain
Rear Derailleur
SRAM X9 Type 2
Front Derailleur
SRAM Apex
Shift Levers
SRAM Apex
Cassette
SRAM PG1030 11-32t 10 spd
Crank
36/46t
Bottom Bracket
SRAM GXP
Chain
KMC X10
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Alex CXD7 Wheelset
Rear Hub
Alex CXD7 Wheelset
Rims
Alex CXD7 Wheelset
Spokes
Alex CXD7 Wheelset
Tires
Freedom Ryder 700x35C
Brakes
Brakes
Hayes CX Expert
Brake Levers
SRAM Apex
Disk Rotors
Hayes L Series 160mm
Cockpit
Stem
Kona XC/Road Light
Handlebar
Kona Road Bar
Grips
Kona Cork Tape
Headset
FSA No.11
Seat
Saddle
WTB Volt Comp
Seatpost
Kona Double Clamp w/Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 53cm | 56cm | 59cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.45 mm | 1.51 mm | 1.55 mm | 1.55 mm | 1.54 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 592 mm | 598 mm | 604 mm | 609 mm | 624 mm | 633 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 92 mm | 78 mm | 75 mm | 70 mm | 68 mm | 64 mm |
| Stack | 529 mm | 550 mm | 576 mm | 596 mm | 617 mm | 629 mm |
| Reach | 387 mm | 380 mm | 382 mm | 385 mm | 399 mm | 409 mm |
| Top Tube Length | 522 mm | 537 mm | 552 mm | 567 mm | 587 mm | 607 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 530 mm | 560 mm | 590 mm | 610 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 100 mm | 120 mm | 145 mm | 165 mm | 185 mm | 195 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1020 mm | 1027 mm | 1033 mm | 1038 mm | 1053 mm | 1062 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 760 mm | 780 mm | 811 mm | 835 mm | 860 mm | 874 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
ROVE is part of the Kona Rove model. 49 bikes variations carry this model name so far. You can get a glimpse at all models from 2014, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
ROVE components
Fork material
When it comes to the fork, this bike has a steel one, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
As for the wheels, Kona ROVE 2014, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The ROVE comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
