Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b -
Groupset Rival 1, Apex -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
48cm
147cm - 160cm
50cm
152cm - 170cm
52cm
157cm - 182cm
54cm
167cm - 188cm
56cm
175cm - 195cm
58cm
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Butted Cromoly
Suspension Fork
Kona Project Two Cromoly Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
SRAM Rival 1
Front Derailleur
n/a
Shift Levers
SRAM Rival 1
Cassette
SRAM PG1130 11-42t 11spd
Crank
SRAM Apex, 40t X-Sync
Bottom Bracket
SRAM GXP 68mm
Chain
SRAM PC1110
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Formula 100x12mm (centerlock)
Rear Hub
Formula 142x12mm (centerlock)
Rims
WTB ST i23 TCS 2.0
Spokes
Stainless Black 14g
Tires
WTB Venture TCS DUAL 650x47c
Brakes
Brakes
TRP HDC711C Mechanical / Hydraulic
Brake Levers
SRAM Rival 1
Disk Rotors
TRP TR160mm
Cockpit
Stem
Kona Road Deluxe
Handlebar
Kona Road
Grips
Kona Cork Tape
Headset
FSA No.1/No.10
Seat
Saddle
WTB Volt
Seatpost
Kona Deluxe Thumb w/Offset 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.46 mm | 1.49 mm | 1.52 mm | 1.56 mm | 1.57 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 270 mm | 270 mm | 272 mm | 272 mm |
| Front Center | 592 mm | 604 mm | 612 mm | 623 mm | 628 mm | 643 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 64 mm | 64 mm | 61 mm | 61 mm | 58 mm | 58 mm |
| Stack | 527 mm | 546 mm | 565 mm | 583 mm | 602 mm | 621 mm |
| Reach | 367 mm | 373 mm | 378 mm | 383 mm | 387 mm | 395 mm |
| Top Tube Length | 510 mm | 526 mm | 541 mm | 557 mm | 573 mm | 593 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 90 mm | 110 mm | 130 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1011 mm | 1024 mm | 1031 mm | 1043 mm | 1049 mm | 1063 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 72 mm | 72 mm | 70 mm | 70 mm |
| Standover Height | 730 mm | 749 mm | 770 mm | 789 mm | 810 mm | 829 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 147 cm | 152 cm | 157 cm | 167 cm | 175 cm | 180 cm |
| Rider Max Height | 160 cm | 170 cm | 182 cm | 188 cm | 195 cm | 195 cm |
About this model
Rove DL is part of the Kona Rove model. 49 bikes variations carry this model name so far. You can easily view all of the Kona Rove bikes models from 2022, here.
Model range prices
Kona Rove AL 700 2022 is the cheapest bike model and costs 949$. Kona Rove LTD 2022 is the most expensive one and costs 2599$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2022 for 1999$. In conclusion, this bike price is 23.16% smaller than the price of the average Gravel bike.
Rove DL components
Fork material
Rove DL has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
When it comes to wheels, the Rove DL bike is equipped with the aluminum model. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Rove DL has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Rove DL comes in 6 sizes, that range from 147 cm – 195 cm (4.82 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
