Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b -
Groupset Force 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
48cm
147cm - 160cm
50cm
152cm - 170cm
52cm
157cm - 182cm
54cm
167cm - 188cm
56cm
175cm - 195cm
58cm
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 853 Butted Cromoly
Suspension Fork
Kona Full Carbon Flat mount CX Race Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
SRAM Force 1
Front Derailleur
n/a
Shift Levers
SRAM Force 1
Cassette
SRAM XG1150 10-42t 11spd
Crank
SRAM Force 1 X-Sync, 40t X-Sync
Bottom Bracket
SRAM GXP 68mm
Chain
SRAM PC1110
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Formula 100x12mm
Rear Hub
Formula 142x12mm
Rims
WTB Asym i23 TCS
Spokes
Stainless Black 14g
Tires
WTB Horizon Road Plus TCS 650x47c
Brakes
Brakes
SRAM Force 1 Flat Mount
Brake Levers
SRAM Force 1 HRD
Disk Rotors
SRAM Centerline 160mm
Cockpit
Stem
Kona Road
Handlebar
Kona Road
Grips
Kona Cork Tape
Headset
FSA No.57E
Seat
Saddle
WTB Volt Comp
Seatpost
Kona Thumb w/Offset 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.49 mm | 1.53 mm | 1.56 mm | 1.58 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 270 mm | 270 mm | 272 mm | 272 mm |
| Front Center | 587 mm | 599 mm | 606 mm | 618 mm | 624 mm | 639 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 69 mm | 66 mm | 66 mm | 62 mm | 63 mm |
| Stack | 525 mm | 545 mm | 565 mm | 585 mm | 605 mm | 625 mm |
| Reach | 368 mm | 373 mm | 378 mm | 383 mm | 387 mm | 395 mm |
| Top Tube Length | 510 mm | 526 mm | 541 mm | 558 mm | 574 mm | 594 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 102 mm | 123.2 mm | 144.5 mm | 165.6 mm | 187.6 mm | 207.9 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1006 mm | 1018 mm | 1026 mm | 1038 mm | 1045 mm | 1059 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 72 mm | 72 mm | 70 mm | 70 mm |
| Standover Height | 730 mm | 750 mm | 770 mm | 790 mm | 810 mm | 830 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 147 cm | 152 cm | 157 cm | 167 cm | 175 cm | 180 cm |
| Rider Max Height | 160 cm | 170 cm | 182 cm | 188 cm | 195 cm | 195 cm |
About this model
Rove LTD belongs to the Kona Rove model. There are 49 bikes that carry this model name. You can easily view all of the Kona Rove bikes models from 2019, here.
Model range prices
Kona Rove 2019 is the most affordable bike of this model and has a price of 849$. On the other hand, Kona Rove LTD 2019, is the most expensive and costs 3599$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3599$. If we compare this with the average Gravel bike cost we notice that the price is 46.18% higher.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Kona Rove LTD 2019, has a aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Rove LTD comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 147 cm – 195 cm (4.82 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
