Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 160mm -
Travel Rear 160mm -
Fork RockShox Domain
-
Groupset X7, X5 -
Suspension Full -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Clump 7005 Aluminum 160mm Travel
Suspension Fork
Rock Shox Domain R CL 160mm w/20mm TA
Rear Shock
Kona/Fastrax Coil R
Drivetrain
Rear Derailleur
SRAM X-7 Short/Alloy Cage
Front Derailleur
SRAM X-7/E*13 Dual Ring Guide
Shift Levers
SRAM X-5
Cassette
SRAM 950 PowerGlide 11-34 9 spd
Crank
36/24/E*13
Bottom Bracket
FSA
Chain
SRAM 951 PowerChain
Pedals
Kona JackShit
Wheels
Front Hub
20mm Formula Disc
Rear Hub
12mm x 135mm Formula Disc
Rims
Sun Estate
Spokes
Sandvik Stainless 14g
Tires
Maxxis Minion DHF 26x2.5
Brakes
Brakes
Avid Elixir 5
Brake Levers
Avid Elixir 5
Disk Rotors
Avid G3 Clean Sweep 203mm
Cockpit
Stem
Kona DH
Handlebar
Kona DH
Grips
Kona G-LOG
Headset
FSA Orbit ZeroStack Tapered 1.5E
Seat
Saddle
WTB Pure V Comp
Seatpost
Kona DH
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 381 | 43.2cm | 45.7cm | 48.3cm | 20" |
|---|---|---|---|---|---|
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm | 348 mm |
| Front Center | 704 mm | 729 mm | 743 mm | 755 mm | 769 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Top Tube Length | 570 mm | 595 mm | 608 mm | 620 mm | 633 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 457 mm | 483 mm | mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 120 mm | 125 mm | 130 mm | 135 mm | 140 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1142 mm | 1167 mm | 1181 mm | 1193 mm | 1207 mm |
| Bottom Bracket Drop | -5 mm | -5 mm | -5 mm | -5 mm | -5 mm |
| Standover Height | 758 mm | 786 mm | 798 mm | 810 mm | 823 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
About this model
STINKY TL belongs to the Kona Stinky model. 14 bikes variations carry this model name so far. You can get a glimpse at all models from 2011, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro bikes
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
Kona STINKY TL 2011 bike is equipped with the RockShox Domain fork, and has 160mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this bike is Kona/Fastrax Coil R, with a travel distance of 160mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When it comes to wheels, the STINKY TL bike is equipped with the 26″ aluminum model. These wheels give you great handling over your bike. However, they provide less traction than 29″ wheels do.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The STINKY TL comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
