Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Deore, Alivio -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
52cm
157cm - 177cm
54cm
175cm - 188cm
56cm
175cm - 195cm
58cm
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Cromoly Butted
Suspension Fork
Kona Project Two Cromoly Disc Touring
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Deore SGS
Front Derailleur
Shimano Alivio
Shift Levers
Shimano BarCon
Cassette
Shimano Alivio 11-34t 9spd
Crank
28/36/48t
Bottom Bracket
Shimano Deore
Chain
KMC HG53
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Shimano Deore 100x10mm
Rear Hub
Shimano Deore 135x10mm
Rims
WTB SX19
Spokes
Sandvik Stainless Black 14g
Tires
Clement X'Plor MSO 700x40c
Brakes
Brakes
Hayes CX Expert
Brake Levers
Tektro RRL-A
Disk Rotors
Hayes L-Series 160mm
Cockpit
Stem
Kona Road
Handlebar
Kona Road
Grips
Kona Cork Tape
Headset
FSA TH848
Seat
Saddle
Brooks B17 Leather
Seatpost
Kona Deluxe Thumb w/Offset 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 48.5cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.48 mm | 1.49 mm | 1.56 mm | 1.6 mm | 1.63 mm |
| Bottom Bracket Height | 282 mm | 282 mm | 282 mm | 282 mm | 282 mm | 282 mm |
| Front Center | 596 mm | 604 mm | 613 mm | 624 mm | 635 mm | 648 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 66 mm | 67 mm | 68 mm | 67 mm | 67 mm | 67 mm |
| Stack | 541 mm | 550 mm | 560 mm | 590 mm | 610 mm | 632 mm |
| Reach | 366 mm | 372 mm | 377 mm | 378 mm | 382 mm | 387 mm |
| Top Tube Length | 519 mm | 532 mm | 545 mm | 561 mm | 577 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 460 mm | 485 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 147 mm | 168 mm | 191 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1023 mm | 1031 mm | 1039 mm | 1051 mm | 1062 mm | 1075 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 737 mm | 757 mm | 777 mm | 802 mm | 822 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Sutra belongs to the Kona Sutra model. 26 bikes variations carry this model name so far. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Kona Sutra 2017 is the most affordable bike of this model and has a price of 1399$. On the other hand, Kona Sutra LTD 2017, is the most expensive and costs 1999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Kona released this model in 2017, its price was 1399$. Comparing the average cost of a Gravel bike to this one, you will see that Sutra price is 75.98% lower.
Sutra components
Fork material
The fork is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
When it comes to wheels, the Sutra bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
