Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Deore, microSHIFT -
Suspension Rigid -
Drivetrain 3 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
48cm
147cm - 160cm
50cm
152cm - 170cm
52cm
157cm - 177cm
54cm
175cm - 188cm
56cm
175cm - 195cm
58cm
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Cromoly Butted
Suspension Fork
Kona Project Two Cromoly Disc Touring
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Deore SGS
Front Derailleur
Shimano Deore
Shift Levers
MicroShift
Cassette
Shimano Deore 11-36t 10spd
Crank
Shimano Deore, 26/36/48t
Bottom Bracket
Shimano 73mm
Chain
Shimano Deore
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Formula 100x12mm
Rear Hub
Formula 142x12mm
Rims
WTB ST i23 TCS 2.0
Spokes
Stainless Black 14g
Tires
Schwalbe Marathon Mondial 700x40c
Brakes
Brakes
TRP Spyre C Flat mount
Brake Levers
Tektro RRL-A
Disk Rotors
TRP Spyre C 160mm
Cockpit
Stem
Kona Road
Handlebar
Kona Road
Grips
Kona Cork Tape
Headset
FSA TH848
Seat
Saddle
Brooks B17 Leather
Seatpost
Kona Deluxe Thumb w/Offset 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.48 mm | 1.49 mm | 1.56 mm | 1.6 mm | 1.63 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm | 283 mm | 283 mm | 283 mm |
| Front Center | 596 mm | 604 mm | 613 mm | 624 mm | 635 mm | 648 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 66 mm | 67 mm | 68 mm | 67 mm | 67 mm | 67 mm |
| Stack | 541 mm | 550 mm | 560 mm | 590 mm | 610 mm | 632 mm |
| Reach | 366 mm | 372 mm | 377 mm | 378 mm | 382 mm | 387 mm |
| Top Tube Length | 519 mm | 532 mm | 545 mm | 561 mm | 577 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 460 mm | 485 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 147 mm | 168 mm | 191 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1023 mm | 1031 mm | 1039 mm | 1051 mm | 1062 mm | 1075 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 737 mm | 757 mm | 777 mm | 802 mm | 822 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 147 cm | 152 cm | 157 cm | 175 cm | 175 cm | 180 cm |
| Rider Max Height | 160 cm | 170 cm | 177 cm | 188 cm | 195 cm | 195 cm |
About this model
Sutra is a Kona Sutra model. 26 bikes variations carry this model name so far. You can easily view all of the Kona Sutra bikes models from 2021, here.
Model range prices
Kona Sutra 2021 is the most economical model, with a starting price of 1699$. Kona Sutra ULTD 2021 on the other hand costs 2599$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Kona released this model in 2021, its price was 1699$. In conclusion, this bike price is 44.91% lower than the price of the average Gravel bike.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
The wheels on Sutra are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Sutra has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Kona Sutra bike has 6 sizes, in the range of 147 cm – 195 cm (4.82 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
