Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Deore, Alivio -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
52cm
157cm - 177cm
54cm
175cm - 188cm
56cm
175cm - 195cm
58cm
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Cromoly Butted
Suspension Fork
Kona Project Two Cromoly Disc Touring
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Deore SGS
Front Derailleur
Shimano Alivio
Shift Levers
Shimano BarCon
Cassette
Shimano Alivio 11-34t 9spd
Crank
Shimano Deore, 26/36/48t
Bottom Bracket
Shimano 73mm
Chain
KMC X9
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Formula 100x12mm
Rear Hub
Formula 142x12mm
Rims
WTB STP i19 TCS
Spokes
Stainless Black 14g
Tires
Schwalbe Marathon Mondial 700x40c
Brakes
Brakes
TRP Spyre C
Brake Levers
Tektro RRL-A
Disk Rotors
TRP TR160 160mm
Cockpit
Stem
Kona Road
Handlebar
Kona Road
Grips
Kona Cork Tape
Headset
FSA TH848
Seat
Saddle
Brooks B17 Leather
Seatpost
Kona Deluxe Thumb w/Offset 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 48.5cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.48 mm | 1.49 mm | 1.56 mm | 1.6 mm | 1.63 mm |
| Bottom Bracket Height | 282 mm | 282 mm | 282 mm | 282 mm | 282 mm | 282 mm |
| Front Center | 596 mm | 604 mm | 613 mm | 624 mm | 635 mm | 648 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 66 mm | 67 mm | 68 mm | 67 mm | 67 mm | 67 mm |
| Stack | 541 mm | 550 mm | 560 mm | 590 mm | 610 mm | 632 mm |
| Reach | 366 mm | 372 mm | 377 mm | 378 mm | 382 mm | 387 mm |
| Top Tube Length | 519 mm | 532 mm | 545 mm | 561 mm | 577 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 460 mm | 485 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 147 mm | 168 mm | 191 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1023 mm | 1031 mm | 1039 mm | 1051 mm | 1062 mm | 1075 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 737 mm | 757 mm | 777 mm | 802 mm | 822 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Sutra TA belongs to the Kona Sutra model. 26 bikes variations carry this model name so far. You can easily view all of the Kona Sutra bikes models from 2018, here.
Model range prices
The most economical model, the Kona Sutra 2018 has a starting price of 1399$. Kona Sutra LTD 2018 on the other hand is the most expensive at 2099$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Kona Sutra TA price was 1499$. Comparing the average cost of a Gravel bike to this one, you will see that Sutra TA price is 64.24% lower.
Overview of components
Fork material
The fork is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
As for the wheels, Kona Sutra TA 2018, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona Sutra TA is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
