Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 130mm -
Fork RockShox Revelation RC
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Scandium 69 Butted Aluminum
Suspension Fork
RockShox Revelation 130mm RLT 15mm TA
Rear Shock
Fox Float RP2 XV BSD
Drivetrain
Rear Derailleur
Shimano Deore XT Shadow SGS
Front Derailleur
Shimano SLX
Shift Levers
Shimano SLX
Cassette
Shimano HG81 11-36 10 spd
Crank
42/32/24
Bottom Bracket
Shimano Deore XT
Chain
Shimano HG74
Pedals
Shimano M530 Clipless
Wheels
Front Hub
Easton EA 70 XCT Wheelset
Rear Hub
Easton EA 70 XCT Wheelset
Rims
Easton EA 70 XCT Wheelset
Spokes
Easton EA 70 XCT Wheelset
Tires
Maxxis Ardent 26x2.25 Kevlar
Brakes
Brakes
Avid Elixir 7
Brake Levers
Avid Elixir 7
Disk Rotors
Avid HS1
Cockpit
Stem
Kona XC/BC
Handlebar
Kona XC/BC Primo Riser
Grips
Kona Race Light LOG
Headset
FSA No.57B
Seat
Saddle
WTB Valcon Race
Seatpost
Kona Primo Double Clamp w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 16" | 17" | 18" | 19" | 20" | 22" |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.35 mm | 1.33 mm | 1.31 mm | 1.29 mm | 1.26 mm | 1.22 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm | 350 mm | 350 mm | 350 mm |
| Front Center | 685 mm | 695 mm | 710 mm | 725 mm | 735 mm | 750 mm | 775 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Stack | 557 mm | 562 mm | 567 mm | 572 mm | 577 mm | 582 mm | 592 mm |
| Reach | 407 mm | 417 mm | 427 mm | 437 mm | 447 mm | 462 mm | 487 mm |
| Top Tube Length | 567 mm | 582 mm | 592 mm | 607 mm | 617 mm | 632 mm | 657 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 405 mm | 430 mm | 455 mm | 485 mm | 510 mm | 560 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 120 mm | 130 mm | 135 mm | 140 mm | 145 mm | 150 mm | 160 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1107 mm | 1122 mm | 1137 mm | 1152 mm | 1162 mm | 1172 mm | 1197 mm |
| Bottom Bracket Drop | -7 mm | -7 mm | -7 mm | -7 mm | -7 mm | -7 mm | -7 mm |
| Standover Height | 757 mm | 752 mm | 767 mm | 782 mm | 797 mm | 812 mm | 842 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" | 26" |
Model Overview
Tanuki Supreme belongs to the Kona Tanuki model. There are 8 bikes that carry this model name. Check out the entire range from 2012 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
The fork installed on this bike is the RockShox Revelation RC model. The travel on this model is 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the Tanuki Supreme bike is equipped with the 26″ aluminum model. These wheels give you great handling over your bike. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
When you want to stop the bike in time, the brakes are vital. The Tanuki Supreme has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
