Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 29" -
Fork Suntour XCR 32 Air -
Groupset Deore -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUMINIUM SUPERLITE
Suspension Fork
SR SUNTOUR XCR 32 RLR AIR
Rear Shock
SR SUNTOUR EDGE R
Drivetrain
Rear Derailleur
SHIMANO DEORE M5100
Front Derailleur
NO
Shift Levers
SHIMANO DEORE M5100
Cassette
SHIMANO DEORE M5100 11-51T
Crank
SHIMANO DEORE M5100
Bottom Bracket
SHIMANO BSA BB52
Chain
SHIMANO HG601
Pedals
NO
Wheels
Front Hub
SHIMANO MT400 15x110
Rear Hub
SHIMANO MT400 12x148
Rims
KROSS
Tires
SCHWALBE RAPID ROB 29x2.25
Brakes
Brakes
SHIMANO MT200
Brake Levers
SHIMANO MT200
Cockpit
Stem
ALUMINIUM/31,8/ (S- 70MM/17°, M- 80MM/12°, L- 80MM/12°, XL- 90MM/12°)
Handlebar
ALUMINIUM 740 MM 31.8
Headset
FP-H856B2;1-1/8"-1.5"
Seat
Saddle
SELLE ROYAL
Seatpost
ALUMINIUM/ (S- 30,9x350MM, M- 30,9x350MM, L- 30,9x400MM, XL- 30,9x400MM)
Motor & Battery
Remote
NO
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.435 mm | 1.353 mm | 1.324 mm | 1.255 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm | 334 mm |
| Front Center | 683 mm | 708 mm | 733 mm | 758 mm |
| Rake | 53 mm | 53 mm | 53 mm | 53 mm |
| Trail | 91 mm | 91 mm | 91 mm | 91 mm |
| Stack | 587 mm | 587 mm | 601 mm | 601 mm |
| Reach | 409 mm | 434 mm | 454 mm | 479 mm |
| Top Tube Length | 575 mm | 600 mm | 625 mm | 650 |
| Seat Tube Angle | 74.3 ° | 74.3 ° | 74.2 ° | 74.2 ° |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 100 mm | 115 mm | 115 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1115 mm | 1140 mm | 1165 mm | 1190 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm | 40 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
EARTH 1.0 is part of the Kross Earth model. There are 15 bikes that carry this model name. Check out the entire range from 2022 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
This bike has the Suntour XCR 32 Air fork installed. The fork’s travel is mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When leaving the production line, the EARTH 1.0 model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The EARTH 1.0 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
EARTH 1.0 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
