Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Fork RockShox SID -
Groupset GX Eagle -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CARBON D84
Suspension Fork
ROCK SHOX SID RL R
Rear Shock
NO
Drivetrain
Rear Derailleur
SRAM GX EAGLE
Front Derailleur
NO
Shift Levers
SRAM GX EAGLE
Cassette
SRAM 1275 EAGLE 10-50T
Crank
SRAM GX EAGLE
Bottom Bracket
SRAM PRESS FIT DUB
Chain
SRAM GX EAGLE
Pedals
NO
Wheels
Front Hub
DT SWISS 15x110
Rear Hub
DT SWISS 12x142
Rims
DT SWISS X 1700 25mm
Tires
MITAS SCYLLA V75 29X2.25
Brakes
Brakes
SRAM LEVEL TL
Brake Levers
SRAM LEVEL TL
Cockpit
Stem
ALUMINIUM/ 31,8/17° (S- 70MM, M- 70MM, L- 80MM, XL- 80MM)
Handlebar
ALUMINIUM 720 MM 31.8
Headset
FSA Orbit C-40-CF-ACB
Seat
Saddle
SELLE ROYAL
Seatpost
ALUMINIUM/ 27,2 (S- 350MM, M- 350MM, L- 400MM, XL- 400MM)
Motor & Battery
Remote
NO
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.516 mm | 1.457 mm | 1.406 mm | 1.386 mm |
| Bottom Bracket Height | 317 mm | 317 mm | 317 mm | 317 mm |
| Front Center | 658 mm | 678 mm | 704 mm | 720 mm |
| Rake | 46 mm | 46 mm | 46 mm | 45 mm |
| Trail | 94 mm | 94 mm | 94 mm | 96 mm |
| Stack | 602 mm | 606 mm | 616 mm | 625 mm |
| Reach | 397 mm | 416 mm | 438 mm | 451 mm |
| Top Tube Length | 570 mm | 590 mm | 615 mm | 630 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1086 mm | 1106 mm | 1132 mm | 1148 mm |
| Bottom Bracket Drop | 57 mm | 57 mm | 57 mm | 57 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
LEVEL 14.0 completes the Kross Level model. Kross released 92 bikes variations of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
LEVEL 14.0 components
Fork
This bike has the RockShox SID fork installed. The fork’s travel is mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When it comes to wheels, the LEVEL 14.0 bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The LEVEL 14.0 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
LEVEL 14.0 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
