Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Fork RockShox SID -
Groupset XTR, FSA -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CARBON D84
Suspension Fork
ROCK SHOX SID WC
Rear Shock
NO
Drivetrain
Rear Derailleur
SHIMANO XTR M9100
Front Derailleur
NO
Shift Levers
SHIMANO XTR M9100
Cassette
SHIMANO XTR M9100 10-51T
Crank
FSA SL-K
Bottom Bracket
FSA BB392
Chain
SHIMANO M9100
Pedals
NO
Wheels
Front Hub
DT SWISS 15x110
Rear Hub
DT SWISS 12x142
Rims
DT SWISS XRC 1200 CARBON
Tires
MITAS SCYLLA V75 29X2.25
Brakes
Brakes
SHIMANO XTR M9120
Brake Levers
SHIMANO XTR M9120
Cockpit
Stem
FSA K-FORCE/ 31,8/12° (S- 80MM, M- 80MM, L- 90MM, XL- 90MM)
Handlebar
FSA K-FORCE 760MM 31.8 DI2
Headset
FSA Orbit C-40-CF-ACB
Seat
Saddle
F'IZI:K TUNDRA M3 CARBON
Seatpost
FSA K-FORCE SB0/ 27.2 (S- 350MM, M- 350MM, L- 400MM, XL- 400MM)
Motor & Battery
Remote
NO
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.516 mm | 1.457 mm | 1.406 mm | 1.386 mm |
| Bottom Bracket Height | 317 mm | 317 mm | 317 mm | 317 mm |
| Front Center | 658 mm | 678 mm | 704 mm | 720 mm |
| Rake | 46 mm | 46 mm | 46 mm | 45 mm |
| Trail | 94 mm | 94 mm | 94 mm | 96 mm |
| Stack | 602 mm | 606 mm | 616 mm | 625 mm |
| Reach | 397 mm | 416 mm | 438 mm | 451 mm |
| Top Tube Length | 570 mm | 590 mm | 615 mm | 630 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1086 mm | 1106 mm | 1132 mm | 1148 mm |
| Bottom Bracket Drop | 57 mm | 57 mm | 57 mm | 57 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
LEVEL TE completes the Kross Level model. 92 bikes variations carry this model name so far. Check out the entire range from 2021 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
The LEVEL TE comes factory-installed with the RockShox SID fork. This has a travel range of mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The LEVEL TE 2021 bike is equipped with 29″ carbon wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The LEVEL TE comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
