Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Fork Suntour NEX -
Groupset Deore, Tourney -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUMINIUM PERFORMANCE
Suspension Fork
SR SUNTOUR NEX
Rear Shock
NO
Drivetrain
Rear Derailleur
SHIMANO DEORE M592
Front Derailleur
SHIMANO TOURNEY TY710
Shift Levers
SHIMANO EF505
Cassette
SHIMANO HG31 11-32T
Crank
SR SUNTOUR
Bottom Bracket
FP-B902
Chain
YBN S8
Pedals
FP-910
Wheels
Front Hub
SHIMANO DH3D37
Rear Hub
SHIMANO TX505
Rims
KROSS
Tires
SCHWALBE SILENTO 42-622
Brakes
Brakes
SHIMANO MT200
Brake Levers
SHIMANO EF505
Cockpit
Stem
ALUMINIUM 110MM/25,4
Handlebar
STEEL 600MM
Headset
FP-H805A; 1 1/8"
Seat
Saddle
KROSS
Seatpost
ALUMINIUM 27,2x350 AMO
Motor & Battery
Remote
NO
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.584 mm | 1.544 mm | 1.488 mm | 1.498 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 276 mm |
| Front Center | 631 mm | 641 mm | 657 mm | 672 mm |
| Rake | 40 mm | 40 mm | 41 mm | 39 mm |
| Trail | 80 mm | 80 mm | 79 mm | 81 mm |
| Stack | 610 mm | 610 mm | 610 mm | 629 mm |
| Reach | 385 mm | 395 mm | 410 mm | 420 mm |
| Top Tube Length | 541 mm | 570 mm | 585 mm | 600 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 140 mm | 140 mm | 140 mm | 160 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1084 mm | 1094 mm | 1110 mm | 1125 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
TRANS 5.0 completes the Kross Trans model. 50 bikes variations carry this model name so far. You can easily view all of the Kross Trans bikes models from 2022, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Touring bikes
According to our calculations, the average cost of a Touring bike that is reliable is 1007$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Touring bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The TRANS 5.0 comes factory-installed with the Suntour NEX fork. This has a travel range of mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on TRANS 5.0 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The TRANS 5.0 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Kross TRANS 5.0 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
