Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Fox AWL
-
Groupset XT -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTUBE 750Wh SMART SYSTEM hor. -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Macina Trekking Onroad Alloy6061; PT750Wh Bosch Gen.4 / T-2940
Suspension Fork
FOX 34 Float AWL 27.5" e-bike 100mm 15x110
Drivetrain
Rear Derailleur
Shimano Deore XT M8130-11 LG shadow+
Shift Levers
Shimano Deore XT M8130-11 LG
Cassette
Shimano LG400-11 / 11-50
Crank
KTM E-TEAM ISIS 170mm Q16
Bottom Bracket
Bosch, press-fit
Chain
KMC e11 Sport EPT e-bike
Pedals
MTB-Pedal flat VPE-527 alloy
Wheels
Rims
KTM Line - DT Swiss 370 CL R28 110/15 SS HY Straight Pull / Ambrosio E30 Trail 28H 584x30TC / DT Hybrid 2.34 straightpull black
Brakes
Brakes
Shimano Deore XT T8100 / M8120 4-Piston
Cockpit
Stem
KTM adjust. 0-60° ICR
Handlebar
KTM Team rizer15 680mm
Headset
Acros AICR internal 1.1/8"-1.5" angle limit
Seat
Saddle
Selle Royal Lookin+
Seatpost
KTM Team 30.9/300
Motor & Battery
Motor
Bosch PERFORMANCE CX Gen.4 SMART SYSTEM - 25km/h / 85Nm
Battery
Bosch PowerTUBE 750Wh SMART SYSTEM hor.
Charger
Bosch STANDARD Charger 4A SMART SYSTEM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.75 mm | 1.76 mm | 1.77 mm | 1.76 mm | 1.69 mm |
| Bottom Bracket Height | 304 mm | 304 mm | 304 mm | 304 mm | 304 mm |
| Front Center | 659 mm | 653 mm | 654 mm | 669 mm | 689 mm |
| Rake | 41 mm | 42 mm | 44 mm | 43 mm | 44 mm |
| Trail | 108 mm | 100 mm | 91 mm | 92 mm | 91 mm |
| Stack | 629 mm | 635 mm | 648 mm | 663 mm | 668 mm |
| Reach | 359 mm | 361 mm | 366 mm | 376 mm | 395 mm |
| Top Tube Length | 581 mm | 586 mm | 596 mm | 611 mm | 631 mm |
| Seat Tube Angle | 70.3 ° | 70.3 ° | 70.3 ° | 70.3 ° | 70.3 ° |
| Seat Tube Length | 430 mm | 460 mm | 510 mm | 560 mm | 600 mm |
| Head Tube Angle | 66.8 ° | 67.8 ° | 68.7 ° | 68.7 ° | 68.8 ° |
| Head Tube Length | 165 mm | 165 mm | 174 mm | 190 mm | 195 mm |
| Chainstay Length | 483 mm | 483 mm | 483 mm | 483 mm | 483 mm |
| Wheelbase | 1137 mm | 1131 mm | 1132 mm | 1147 mm | 1167 mm |
| Bottom Bracket Drop | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Standover Height | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
MACINA AERA 771 LFC is part of the Ktm E Macina Aera model. 16 e-bikes variations carry this model name so far. You can easily view all of the Ktm E Macina Aera e-bikes models from 2023, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry e-bikes average price
According to our math, the average price for a trustworthy Crosscountry e-bike is 2453$. However, you could also get a good Crosscountry e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Crosscountry e-bikes average weight
If we make a quick analysis of the average weight of a Crosscountry e-bike, we get 23.21 kg (51.17 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 27.4 kg (60.41 lbs), KTM e-bike is much heavier than average. To sum up, it’s 18.05% heavier than the average weight of Crosscountry e-bikes.
Overview of components
Fork
KTM MACINA AERA 771 LFC 2023 e-bike is equipped with the Fox AWL fork, and has 100mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The MACINA AERA 771 LFC 2023 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. KTM MACINA AERA 771 LFC has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
