KTM MACINA CENTRAL 7 RT 2021
2021 E-bike
Estimate price |
3,082$
Weight | 24.9 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour
-
Groupset Nexus -
Suspension Hardtail -
Motor Bosch 40Nm mid-drive -
Battery Bosch PowerPACK 400Wh -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Rim
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Macina City US Alloy6061; Si-PP500Wh Bosch Gen.3 / T-9680
Suspension Fork
Suntour CR85-E25 coil 63mm
Drivetrain
Shift Levers
Shimano Nexus 7 Revoshifter
Cassette
Shimano Nexus 22T
Crank
KTM LINE BNI 170mm Q16
Bottom Bracket
Bosch, press-fit
Chain
KMC Z1eHX
Wheels
Rims
KTM Line - Shimano Acera T3000 36H 100-5QR / Ambrosio Track 36H 622x20C / DT Champion 2.0 silver
Brakes
Brakes
Magura HS11 Evo2
Cockpit
Stem
KTM Line UP3 adjust. 0-90°
Handlebar
KTM Line Noirette Plus 660mm
Headset
Ritchey Zero Logic OE 1.1/8"
Seat
Saddle
Selle Royal Essenza
Seatpost
KTM Line Elegance suspension 30.9/300
Motor & Battery
Motor
Bosch ACTIVE Gen.3 - 25km/h / 40Nm
Battery
Bosch PowerPACK 400Wh
Remote
Bosch INTUVIA LCD Display with Remote
Charger
Bosch COMPACT Charger 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.67 mm | 1.65 mm | 1.66 mm | 1.64 mm |
| Front Center | 626 mm | 628 mm | 638 mm | 655 mm |
| Rake | 29 mm | 36 mm | 35 mm | 35 mm |
| Trail | 103 mm | 89 mm | 90 mm | 90 mm |
| Stack | 619 mm | 621 mm | 634 mm | 649 mm |
| Reach | 371 mm | 377 mm | 383 mm | 396 mm |
| Top Tube Length | 586 mm | 593 mm | 601 mm | 616 mm |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Seat Tube Length | 430 mm | 460 mm | 510 mm | 560 mm |
| Head Tube Angle | 69 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 160 mm | 160 mm | 174 mm | 190 mm |
| Chainstay Length | 488 mm | 488 mm | 488 mm | 488 mm |
| Wheelbase | 1107 mm | 1109 mm | 1119 mm | 1137 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
MACINA CENTRAL 7 RT completes the Ktm E Macina Central model. 8 e-bikes variations carry this model name so far. Take a sneak peek at all Ktm E Macina Central e-bikes models from 2021, by clicking here.
Model range prices
KTM MACINA CENTRAL 7 2021 is the cheapest e-bike model and costs 2813$. KTM Macina Central 5 2021 is the most expensive one and costs 3344$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Commuter e-bikes
According to our calculations, the average cost of a Commuter e-bike that is reliable is 2569$. However, you could also get a good Commuter e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2813$. Comparing this to the average Commuter e-bike price, we see that the price is 9.5% more expensive.
Average weight for Commuter e-bikes
Commuter e-bikes have an average weight of 25.2 kg (55.56 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
KTM MACINA CENTRAL 7 RT it’s weighing 24.9 kg (54.9 lbs). At this weight, is slightly lighter than average. In conclusion, the average Commuter e-bike weighs 1.2% more than MACINA CENTRAL 7 RT.
Overview of components
Fork
KTM MACINA CENTRAL 7 RT 2021 e-bike is equipped with the SunTour fork, and has 63mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When it comes to wheels, the MACINA CENTRAL 7 RT e-bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. KTM MACINA CENTRAL 7 RT has Hydraulic Rim brakes installed. These brakes are pretty rare, and you will find them on very few bike models. In short, search for a bike that has hydraulic brakes, as they deliver way better performance.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
