Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" / 27.5" -
Travel Front 150mm -
Travel Rear 160mm -
Fork SunTour Zeron
-
Groupset Deore -
Suspension Full -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch PowerTube, lithium-ion, integrated, removable -
Drivetrain 1 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
SR Suntour Zeron 35 Coil, LOR
Rear Shock
SR Suntour Tri-Air 3CR, 250mm x 70mm
Drivetrain
Rear Derailleur
Shimano Deore M6000-10, 10-speed, SHADOW RD+, GS cage
Front Derailleur
N/A
Shift Levers
Shimano Deore M6000-10, 10-speed, with display
Cassette
Shimano Deore HG500-10, 10-speed, 11-42 tooth
Crank
KTM Comp, ISIS, 160mm length
Chain
Shimano E6090-10 E-Bike, 10-speed
Chain Guide
Upper guide
Pedals
VP-195E alloy
Wheels
Front Hub
Shimano Deore M6010B, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rear Hub
Shimano Deore M6010B, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rims
Ambrosio E30 Trail, 32 hole, 29" front, 27.5" rear
Spokes
DT Swiss Champion, 2.0, black
Tires
Schwalbe Nobby Nic, Performance, TLR, 29" front, 27.5" rear
Brakes
Brakes
Shimano MT420, 4-piston, Shimano RT64 CENTER LOCK rotors (203mm front, 180mm rear)
Brake Levers
Shimano MT420
Cockpit
Stem
KTM Team Trail, 35mm
Handlebar
KTM Comp Trail, 35mm diameter, 15mm rise, 780mm width
Grips
KTM Comp, lock-on
Headset
KTM Team
Seat
Saddle
Selle Italia X3 E-Bike Flow
Seatpost
KTM Comp dropper
Motor & Battery
Motor
Bosch Performance CX Gen.4, 75Nm torque
Battery
Bosch PowerTube, lithium-ion, integrated, removable
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.34 mm | 1.29 mm |
| Front Center | 764 mm | 786 mm | 819 mm |
| Rake | 48 mm | 48 mm | 48 mm |
| Trail | 114 mm | 114 mm | 114 mm |
| Stack | 603 mm | 612 mm | 626 mm |
| Reach | 440 mm | 458 mm | 485 mm |
| Top Tube Length | 586 mm | 606 mm | 636 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 430 mm | 450 mm | 480 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1202 mm | 1224 mm | 1257 mm |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm |
| Standover Height | 800 mm | 803 mm | 808 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Macina Kapoho 2973 completes the Ktm E Macina Kapoho model. There are 26 e-bikes that carry this model name. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Enduro e-bikes average price
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Enduro e-bikes average weight
The average weight for Enduro e-bikes is 23.42 kg (51.63 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Macina Kapoho 2973 weighs 25.3 kg (55.78 lbs) and is a bit heavier than the average. To sum up, it’s 8.03% heavier than the average weight of Enduro e-bikes.
Overview of components
Fork
The SunTour Zeron is included from the factory. It has a travel distance of 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this e-bike is SR Suntour Tri-Air 3CR, with a travel distance of 160mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
As for the wheels, KTM Macina Kapoho 2973 2020, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. KTM Macina Kapoho 2973 has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
Dropper post
The KTM model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
