Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Groupset Nexus -
Suspension Rigid -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerPACK 725Wh SMART SYSTEM -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Macina Multi CX 24" LongTail Alloy 6061; Si-PP800Wh Bosch Gen.4 / C-3020
Suspension Fork
24" alloy cargo
Drivetrain
Shift Levers
Shimano Nexus 5 Revoshifter
Cassette
Gates rear-sprocket 34T Nexus 5
Crank
KTM E-LINE BNI 170mm Q16
Bottom Bracket
Bosch, press-fit
Chain
Gates drive-belt 174T CDX
Chain Guide
KTM type for Multi
Pedals
MTB-Pedal flat VPE-527 alloy
Wheels
Rims
KTM Line - Shimano Deore M6010 CL 36H 100-15TA / Ryde Andra29 36H 507x29C / DT Alpine II 2.34 black
Brakes
Brakes
Shimano MT402 (3-F) / MT420 4-Piston
Cockpit
Stem
Ergotec HighCarisma 50
Handlebar
Ergotec Riserbar 50 -780mm
Headset
Acros AICR internal 1.1/8"-1.5" angle limit
Seat
Saddle
Selle Royal Essenza EPTech
Seatpost
KTM COMP II 34.9 / 350
Motor & Battery
Motor
Bosch PERFORMANCE CX Gen.4 SMART SYSTEM - 25km/h / 85Nm
Battery
Bosch PowerPACK 725Wh SMART SYSTEM
Charger
Bosch STANDARD Charger 4A SMART SYSTEM
Fit data
Geometry
Numbers for sizing and ride feel.
About this model
MACINA MULTI CX is a Ktm E Macina Multi model. 5 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
KTM MACINA MULTI 2023 is the most affordable e-bike of this model and has a price of 4034$. On the other hand, KTM MACINA MULTI URBAN 2023, is the most expensive and costs 4458$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Road e-bikes average price
According to our calculations, the average cost of a Road e-bike that is reliable is 1781$. However, this doesn’t mean that if you spend less money on a Road e-bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Average weight for Road e-bikes
The average weight for Road e-bikes is 29.9 kg (65.92 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 29.9 kg (65.92 lbs), the MACINA MULTI CX model is equally heavier with average. In short, the average Road e-bike weight is 0% lower than this one.
Overview of components
Fork material
MACINA MULTI CX has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
The wheels on MACINA MULTI CX are the 24″ aluminum type. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
Nothing is more important on a bike than its ability to brake properly. KTM MACINA MULTI CX is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
