Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Alivio -
Suspension Hardtail -
Motor Bosch 250W 50Nm mid-drive -
Battery Bosch PowerPACK 500Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Macina MTB 27.5" Alloy6061; UC-PP500Wh Bosch Gen.3 / M-9690
Suspension Fork
Suntour XCM coil 27.5" HLO 100mm
Drivetrain
Rear Derailleur
Shimano Alivio M3100-9 SGS shadow
Shift Levers
Shimano Alivio M3100-9 display
Cassette
Shimano HG201-9 / 11-36
Crank
KTM E-LINE BNI 170mm Q16
Bottom Bracket
Bosch, press-fit
Chain
Shimano E6070-9 e-bike
Pedals
MTB-Pedal C280DU alloy
Wheels
Rims
KTM Line - Shimano Acera M3050 CL 32H 100-5QR / Ryde Rival23 32H 584x23C / DT Champion 2.0 silver
Brakes
Brakes
Shimano MT200 / MT200 2-Piston
Cockpit
Stem
KTM COMP II 7°
Handlebar
KTM COMP II rizer15 680mm
Headset
Ritchey OE Zero Logic 1.1/8"
Seat
Saddle
KTM Line Sport
Seatpost
KTM COMP II 30.9/350
Motor & Battery
Motor
Bosch ACTIVE PLUS Gen.3 - 25km/h / 50Nm
Battery
Bosch PowerPACK 500Wh
Charger
Bosch COMPACT Charger 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.595 mm | 1.567 mm | 1.528 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 308 mm |
| Front Center | 636 mm | 638 mm | 659 mm |
| Rake | 43 mm | 42 mm | 42 mm |
| Trail | 87 mm | 85 mm | 85 mm |
| Stack | 606 mm | 608 mm | 619 mm |
| Reach | 380 mm | 388 mm | 405 mm |
| Top Tube Length | 566 mm | 574 mm | 594 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 400 mm | 430 mm | 480 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70 ° |
| Head Tube Length | 125 mm | 125 mm | 137 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1092 mm | 1094 mm | 1115 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm |
| Standover Height | 763 mm | 770 mm | 792 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
MACINA RIDE 571 is a Ktm E Macina Ride model. KTM launched 9 e-bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry e-bikes
According to our math, the average price for a trustworthy Crosscountry e-bike is 2453$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Average weight for Crosscountry e-bikes
Crosscountry e-bikes weigh an average of 23.21 kg (51.17 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 22.2 kg (48.94 lbs), KTM e-bike is slightly lighter than average. In other words, this model is 4.55% lighter than the average Crosscountry e-bike.
MACINA RIDE 571 components
Fork
The MACINA RIDE 571 comes factory-installed with the Suntour XCM fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
As for the wheels, KTM MACINA RIDE 571 2023, has a 27.5″ aluminum model. These wheels will provide you with more control over the e-bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. KTM MACINA RIDE 571 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
