Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Fox Performance Float 32
-
Groupset XT -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX FLOAT 32 Step-Cast Performance, remote lockout
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XT M8100, 12-speed, SHADOW RD+, SGS cage
Front Derailleur
N/A
Shift Levers
Shimano XT M8100, 12-speed
Cassette
Shimano XT M8100, 12-speed, 10-51 tooth
Crank
Shimano XT M8100
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano XT M8100, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
KTM Comp CC wheelset, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rear Hub
KTM Comp CC wheelset, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rims
KTM Comp CC wheelset, DT Swiss-made rims, tubeless ready
Spokes
KTM Comp CC wheelset
Tires
Front: Maxxis Rekon, 3C MaxxTerra, EXO, TR, Rear: Maxxis Rekon Race, EXO, TR
Brakes
Brakes
Shimano XT M8100, 2-piston, Shimano MT800 CENTER LOCK 160mm Freeza rotors
Brake Levers
Shimano XT M8100
Cockpit
Stem
KTM Team MTB, 7° drop
Handlebar
KTM Team Flat, 720mm width
Grips
KTM Team silicone
Headset
KTM Team drop-in
Seat
Saddle
Ergon SM10
Seatpost
KTM Team, 400mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.41 mm | 1.38 mm | 1.35 mm |
| Bottom Bracket Height | 304 mm | 304 mm | 304 mm | 304 mm |
| Front Center | 653 mm | 674 mm | 695 mm | 715 mm |
| Rake | 51 mm | 52 mm | 51 mm | 51 mm |
| Trail | 75 mm | 74 mm | 75 mm | 75 mm |
| Stack | 596 mm | 605 mm | 615 mm | 624 mm |
| Reach | 411 mm | 428 mm | 446 mm | 463 mm |
| Top Tube Length | 577 mm | 597 mm | 617 mm | 637 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1071 mm | 1092 mm | 1113 mm | 1133 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 758 mm | 769 mm | 800 mm | 829 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
Myroon Master belongs to the Ktm Myroon model. KTM released 25 bikes variations of this model so far. You can easily view all of the Ktm Myroon bikes models from 2020, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Crosscountry bikes
If we make a quick analysis of the average weight of a Crosscountry bike, we get 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Myroon Master weighs 10.2 kg (22.49 lbs) and is much lighter than the average. In conclusion, the average Crosscountry bike weighs 21.57% more than Myroon Master.
Myroon Master components
Fork
The fork installed on this bike is the Fox Performance Float 32 model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
As for the wheels, KTM Myroon Master 2020, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. KTM Myroon Master is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
KTM Myroon Master bike has 4 sizes, in the range of 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, you won’t have a problem finding one that suits you.
