Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Travel Rear 95mm -
Fork RockShox Recon Silver RL
-
Groupset SX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Recon RL, remote lockout
Rear Shock
RockShox Monarch RL, 165mm x 38mm
Drivetrain
Rear Derailleur
SRAM SX Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM SX Eagle, 12-speed, trigger
Cassette
SRAM SX Eagle PG1210, 12-speed, 11-50 tooth
Crank
SRAM SX Eagle DUB
Bottom Bracket
SRAM DUB
Chain
SRAM NX Eagle, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Shimano SLX MT400B, 32 hole, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rear Hub
Shimano SLX MT400B, 32 hole, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rims
DT Swiss 533D, 32 hole
Spokes
DT Swiss Champion, 2.0, black
Tires
Front: Schwalbe Racing Ray, Performance, TLR, Rear: Schwalbe Racing Ralph, Performance, TLR
Brakes
Brakes
Shimano MT201, 2-piston, Shimano RT54 CENTER LOCK rotors (180mm front, 160mm rear)
Brake Levers
Shimano MT201
Cockpit
Stem
KTM Comp, 7° drop
Handlebar
KTM Comp Flat, 720mm width
Grips
KTM Comp, lock-on
Headset
KTM Team drop-in
Seat
Saddle
Ergon SM10
Seatpost
KTM Team, 400mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.36 mm | 1.33 mm |
| Bottom Bracket Height | 329 mm | 329 mm | 329 mm |
| Front Center | 692 mm | 712 mm | 733 mm |
| Rake | 51 mm | 51 mm | 50 mm |
| Trail | 82 mm | 82 mm | 83 mm |
| Stack | 599 mm | 608 mm | 617 mm |
| Reach | 429 mm | 446 mm | 464 mm |
| Top Tube Length | 596 mm | 616 mm | 636 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1125 mm | 1145 mm | 1166 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm |
| Standover Height | 771 mm | 768 mm | 767 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Scarp 294 completes the Ktm Scarp model. There are 42 bikes that carry this model name. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Crosscountry bikes
On a deeper look, we notice that the average weight of a Crosscountry bike is 12.4 kg (27.34 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 14.3 kg (31.53 lbs), the Scarp 294 model is much heavier than average. In other words, this model is 15.32% heavier than the average Crosscountry bike.
Overview of components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the RockShox Monarch RL rear shock model, which has a travel of 95mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, KTM Scarp 294 2020, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Scarp 294 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Scarp 294 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
