Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Recon Silver RL
-
Groupset SX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Scarp 29" Alloy6061 triplebutted; SLL90mm / M-7936
Suspension Fork
RockShox Recon Silver RL 29" 100mm remote 15x110 taper
Rear Shock
RockShox Monarch RL 165x38
Drivetrain
Rear Derailleur
SRAM SX Eagle 12speed
Shift Levers
SRAM SX Eagle Trigger
Cassette
SRAM SX Eagle PG-1210 / 11-50
Crank
SRAM SX Eagle DUB 34T
Chain
SRAM NX Eagle 12s
Wheels
Rims
KTM Line - Shimano MT410B CL 32H 110-15TA / Ryde Rival26 32H 622x26C / DT Champion 2.0 black
Brakes
Brakes
Shimano MT201 / MT200 2-Piston
Cockpit
Stem
KTM Team MTB 7°
Handlebar
KTM COMP II flat 2X 720mm
Headset
KTM Team drop/in 1.1/8"-1.5"
Seat
Saddle
KTM Line Sport
Seatpost
KTM COMP II 30.9/400
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.32 mm | 1.3 mm |
| Bottom Bracket Height | 329 mm | 329 mm | 329 mm |
| Front Center | 714 mm | 735 mm | 756 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 93 mm | 93 mm | 93 mm |
| Stack | 592 mm | 601 mm | 610 mm |
| Reach | 436 mm | 454 mm | 471 mm |
| Top Tube Length | 596 mm | 616 mm | 636 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1141 mm | 1162 mm | 1183 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm |
| Standover Height | 776 mm | 776 mm | 782 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
SCARP 294 is part of the Ktm Scarp model. KTM released 42 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Crosscountry bikes average weight
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
much heavier than average, SCARP 294 has a weight of 14.8 kg (32.63 lbs). In short, the average Crosscountry bike weight is 19.35% lower than this one.
Overview of components
Fork
KTM SCARP 294 2023 bike is equipped with the RockShox Recon Silver RL fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The wheels on SCARP 294 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
KTM SCARP 294 bike has 3 sizes, in the range of 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
