Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Travel Rear 95mm -
Fork Fox Rhythm Float 32
-
Groupset SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX FLOAT 32 Rhythm, remote lockout
Rear Shock
FOX FLOAT DPS Performance Elite, remote lockout, 190mm x 37.5mm
Drivetrain
Rear Derailleur
Shimano SLX M7100, 12-speed SHADOW RD+, SGS cage
Front Derailleur
N/A
Shift Levers
Shimano SLX M7100, 12-speed
Cassette
Shimano SLX M7100, 12-speed, 10-51 tooth
Crank
Shimano SLX M7120
Chain
Shimano SLX M7100, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Shimano SLX M7110B, 32 hole, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rear Hub
Shimano SLX M7110B, 32 hole, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Rims
DT Swiss 533D, 32 hole
Spokes
DT Swiss Champion, 2.0, black
Tires
Maxxis Rekon Race, EXO, TR
Brakes
Brakes
Shimano MT500, 2-piston, Shimano RT54 CENTER LOCK rotors (180mm front, 160mm rear)
Brake Levers
Shimano MT500
Cockpit
Stem
KTM Team MTB, 7° drop
Handlebar
KTM Team Flat, 720mm width
Grips
KTM Team silicone
Headset
KTM Team drop-in
Seat
Saddle
Ergon SM10
Seatpost
KTM Team, 400mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.36 mm | 1.32 mm | 1.29 mm |
| Bottom Bracket Height | 329 mm | 329 mm | 329 mm | 329 mm |
| Front Center | 693 mm | 714 mm | 735 mm | 756 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 93 mm | 93 mm | 93 mm | 93 mm |
| Stack | 583 mm | 593 mm | 602 mm | 611 mm |
| Reach | 420 mm | 437 mm | 455 mm | 472 mm |
| Top Tube Length | 577 mm | 597 mm | 617 mm | 637 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1121 mm | 1142 mm | 1163 mm | 1184 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 777 mm | 777 mm | 777 mm | 783 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Scarp Elite completes the Ktm Scarp model. KTM released 42 bikes variations of this model so far. Take a sneak peek at all Ktm Scarp bikes models from 2020, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Crosscountry bikes
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
KTM Scarp Elite it’s weighing 12.5 kg (27.56 lbs). At this weight, is slightly heavier than average. In short, the average Crosscountry bike weight is 0.81% lower than this one.
Overview of components
Fork
The Fox Rhythm Float 32 is included from the factory. It has a travel distance of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
KTM Scarp Elite bike has the FOX FLOAT DPS Performance Elite model installed, and has a travel of 95mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When leaving the production line, the Scarp Elite model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. KTM Scarp Elite has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
