Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Judy Silver TK
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29" Alloy 6061 MTB ULTRA TB / M-1306
Suspension Fork
RockShox Judy Silver TK 29" 100mm remote 15x110 taper
Drivetrain
Rear Derailleur
Shimano Deore XT M8100-12 SGS shadow+
Shift Levers
Shimano Deore M6100-12
Cassette
Shimano M6100-12 / 10-51
Crank
Shimano Deore M6100 32T
Chain
Shimano M6100-12
Pedals
KTM Team MTB SB
Wheels
Rims
KTM Line - Shimano HB-MT410 CL 32H 110 TA / KTM 28" Sport 32H; 622x22 / Richman 2.0 INOX, black
Brakes
Brakes
Shimano M4100 / MT410 2-Piston
Cockpit
Stem
KTM Team 7°
Handlebar
KTM Comp flat 2X 720mm
Headset
KTM Team drop/in 1.1/8"-1.5"
Seat
Saddle
KTM Comp MTB Sport
Seatpost
KTM Comp 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.47 mm | 1.45 mm | 1.43 mm | 1.44 mm |
| Bottom Bracket Height | 304 mm | 304 mm | 304 mm | 304 mm | 304 mm |
| Front Center | 657 mm | 678 mm | 700 | 721 mm | 738 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 45 mm |
| Trail | 97 mm | 97 mm | 97 mm | 97 mm | 96 mm |
| Stack | 602 mm | 611 mm | 626 mm | 639 mm | 658 mm |
| Reach | 398 mm | 416 mm | 432 mm | 448 mm | 457 mm |
| Top Tube Length | 572 mm | 592 mm | 612 mm | 632 mm | 647 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm | 570 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm | 140 mm | 160 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1085 mm | 1106 mm | 1128 mm | 1149 mm | 1166 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 759 mm | 766 mm | 796 mm | 828 mm | 857 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
ULTRA 1964 COMP 29 belongs to the Ktm Ultra model. There are 36 bikes that carry this model name. Take a sneak peek at all Ktm Ultra bikes models from 2023, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Crosscountry bikes
If we make a quick analysis of the average weight of a Crosscountry bike, we get 12.4 kg (27.34 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
KTM ULTRA 1964 COMP 29 it’s weighing 13.7 kg (30.2 lbs). At this weight, is considerably heavier than average. In other words, this model is 10.48% heavier than the average Crosscountry bike.
Overview of components
Fork
This bike has the RockShox Judy Silver TK fork installed. The fork’s travel is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the ULTRA 1964 COMP 29 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The ULTRA 1964 COMP 29 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
