Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour X1
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29" Alloy 6061 MTB / M-1110
Suspension Fork
Suntour X1 coil 29" RL 100mm
Drivetrain
Rear Derailleur
Shimano Deore M5120-11/10 SGS shadow+
Shift Levers
Shimano Deore M4100-10
Cassette
Shimano M4100-10 / 11-42
Crank
Shimano Deore M4100 36-26T
Chain
Shimano HG54-10
Pedals
KTM Comp MTB BF
Wheels
Rims
KTM Line - Shimano HB-MT200 CL 32H 100 QR / KTM 28" Sport 32H; 622x20 / Pillar 2.0 INOX, silver
Brakes
Brakes
Tektro HD-T275
Cockpit
Stem
KTM Comp 7°
Handlebar
KTM Comp rizer12
Headset
Ritchey OE Zero Logic 1.1/8"
Seat
Saddle
KTM Line Sport
Seatpost
KTM Comp 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.47 mm | 1.45 mm | 1.43 mm | 1.44 mm |
| Bottom Bracket Height | 304 mm | 304 mm | 304 mm | 304 mm | 304 mm |
| Front Center | 657 mm | 678 mm | 700 | 721 mm | 738 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 45 mm |
| Trail | 97 mm | 97 mm | 97 mm | 97 mm | 96 mm |
| Stack | 602 mm | 611 mm | 626 mm | 639 mm | 658 mm |
| Reach | 398 mm | 416 mm | 432 mm | 448 mm | 457 mm |
| Top Tube Length | 572 mm | 592 mm | 612 mm | 632 mm | 647 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm | 570 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm | 140 mm | 160 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1085 mm | 1106 mm | 1128 mm | 1149 mm | 1166 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 759 mm | 766 mm | 796 mm | 828 mm | 857 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
ULTRA FLITE 29 belongs to the Ktm Ultra model. KTM released 36 bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Crosscountry bikes average weight
Crosscountry bikes weigh an average of 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 14.35 kg (31.64 lbs), the ULTRA FLITE 29 model is much heavier than average. In other words, this model is 15.73% heavier than the average Crosscountry bike.
ULTRA FLITE 29 components
Fork
The Suntour X1 is included from the factory. It has a travel distance of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The ULTRA FLITE 29 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The ULTRA FLITE 29 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
