Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset GRX 800, 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
X-Strada Gravel AL6061tb / R-2090
Suspension Fork
X-Strada Gravel Perf. Carbon w/mountings F14
Drivetrain
Rear Derailleur
Shimano GRX RX810-11 shadow+
Front Derailleur
Shimano GRX RX810-2
Shift Levers
Shimano 105 SL-RS700
Cassette
Shimano HG700-11 / 11-34
Crank
Shimano GRX RX600-11 46-30
Chain
Shimano LG500
Wheels
Rims
KTM Line - Shimano 105 R7070 CL 32H 110-12TA / DT Swiss 533D 32H 622x22TC / DT Competition 2.0 black
Brakes
Brakes
Shimano RS600 / RS405 2-Piston
Cockpit
Stem
KTM Team MTB 7°
Handlebar
KTM Team low rizer 640mm
Headset
Acros AICR internal 1.1/8"-1.5" angle limit
Seat
Saddle
Selle San Marco Shortfit Open Fit Wide
Seatpost
KTM Team 27.2/350
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.36 mm | 1.39 mm | 1.37 mm | 1.36 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 266 mm | 268 mm |
| Front Center | 621 mm | 628 mm | 634 mm | 649 mm | 664 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 77 mm | 70 mm | 64 mm | 64 mm | 64 mm |
| Stack | 547.2 mm | 565.1 mm | 587.7 mm | 595.3 mm | 607.5 mm |
| Reach | 404.8 mm | 414.9 mm | 423.4 mm | 435.7 mm | 446.5 mm |
| Top Tube Length | 545 mm | 565 mm | 585 mm | 605 mm | 625 mm |
| Seat Tube Angle | 75.5 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 550 mm | 570 mm | 590 mm |
| Head Tube Angle | 70 ° | 71 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 125 mm | 140 mm | 160 mm | 170 mm | 185 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1045 mm | 1052 mm | 1058 mm | 1074 mm | 1090 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 70 mm | 68 mm |
| Standover Height | 761 mm | 784 mm | 809 mm | 824 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
X-STRADA 10 FIT is a Ktm X Strada model. 26 bikes variations carry this model name so far. Take a sneak peek at all Ktm X Strada bikes models from 2023, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for General Road bikes
According to our math, the average price for a trustworthy General Road bike is 1915$. However, even if your budget is less than the average, you might still be able to get a top-quality General Road bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for General Road bikes
If we make a quick analysis of the average weight of a General Road bike, we get 9 kg (19.84 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 10.3 kg (22.71 lbs), the X-STRADA 10 FIT model is considerably heavier than average. In other words, this model is 14.44% heavier than the average General Road bike.
X-STRADA 10 FIT components
Fork material
X-STRADA 10 FIT has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on X-STRADA 10 FIT are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
X-STRADA 10 FIT comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
