Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset GRX 400, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
X-Strada Gravel AL6061tb / R-2090
Suspension Fork
X-Strada Gravel Perf. Carbon w/mountings F14
Drivetrain
Rear Derailleur
Shimano GRX RX400-10 shadow+
Front Derailleur
Shimano GRX RX400-2
Shift Levers
Shimano GRX RX400
Cassette
Shimano HG50-10 / 11-36
Crank
Shimano GRX RX600-10 46-30
Chain
Shimano HG54-10
Wheels
Rims
KTM Line - Shimano RS470 CL 32H 100-12TA / Ryde Rival23 32H 622x23C / DT Champion 2.0 black
Brakes
Brakes
Shimano GRX RX400 hydraulic
Cockpit
Stem
KTM Team Road 8°
Handlebar
KTM COMP II Road
Headset
Acros AICR internal 1.1/8"-1.5" angle limit
Seat
Saddle
KTM Line Sport
Seatpost
KTM COMP II 27.2/350
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.36 mm | 1.39 mm | 1.37 mm | 1.36 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 266 mm | 268 mm |
| Front Center | 621 mm | 628 mm | 634 mm | 649 mm | 664 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 77 mm | 70 mm | 64 mm | 64 mm | 64 mm |
| Stack | 547.2 mm | 565.1 mm | 587.7 mm | 595.3 mm | 607.5 mm |
| Reach | 404.8 mm | 414.9 mm | 423.4 mm | 435.7 mm | 446.5 mm |
| Top Tube Length | 545 mm | 565 mm | 585 mm | 605 mm | 625 mm |
| Seat Tube Angle | 75.5 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 550 mm | 570 mm | 590 mm |
| Head Tube Angle | 70 ° | 71 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 125 mm | 140 mm | 160 mm | 170 mm | 185 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1045 mm | 1052 mm | 1058 mm | 1074 mm | 1090 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 70 mm | 68 mm |
| Standover Height | 761 mm | 784 mm | 809 mm | 824 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
X-STRADA LFC is a Ktm X Strada model. 26 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
General Road bikes average price
According to our math, the average price for a trustworthy General Road bike is 1915$. However, even if your budget is less than the average, you might still be able to get a top-quality General Road bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for General Road bikes
On a deeper look, we notice that the average weight of a General Road bike is 9 kg (19.84 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 12.2 kg (26.9 lbs), the X-STRADA LFC model is much heavier than average. To sum up, it’s 35.56% heavier than the average weight of General Road bikes.
X-STRADA LFC components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The wheels on X-STRADA LFC are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The X-STRADA LFC comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
