Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 150mm -
Fork RockShox Revelation RC
-
Groupset GX, NX -
Suspension Full -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch Lithium-ion -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
RockShox Revelation RC Solo Air, Boost
Rear Shock
RockShox Deluxe RT DebonAir, 210mm x 52.5mm
Drivetrain
Rear Derailleur
SRAM GX
Front Derailleur
N/A
Shift Levers
SRAM NX, 11-speed
Cassette
SRAM PG-1130, 11-42 tooth, 11-speed
Crank
Race Face Aeffect, 170mm length
Chain
11-speed
Chain Guide
Yes
Pedals
None included
Wheels
Front Hub
Front: Formula DC-711, Boost 15mm x 110mm, Rear: Formula DHT-148s, Boost 12mm x 148mm, Shimano driver
Rear Hub
Front: Formula DC-711, Boost 15mm x 110mm, Rear: Formula DHT-148s, Boost 12mm x 148mm, Shimano driver
Rims
Lapierre eAM+
Tires
Front: Maxxis Minion DHF, 2.8" EXO TR, Rear: Maxxis Rekon+, 2.8" 3c EXO TR
Brakes
Brakes
SRAM Guide RE with 203mm rotors
Brake Levers
SRAM Guide RE
Cockpit
Stem
Lapierre 6061 CNC, 35mm length (S), 45mm length (M-L), 31.8mm clamp
Handlebar
Lapierre Nico Vouilloz 6061DB, 760mm width, 20mm rise, 31.8mm diameter
Headset
FSA Orbit 1.5 ZS (No.57SC)
Seat
Saddle
Lapierre by Velo
Seatpost
Lapierre Dropper, 75mm (S) 125mm (M) 150mm (L), 350mm length
Motor & Battery
Motor
Bosch Performance CX, 250W
Battery
Bosch Lithium-ion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.46 mm | 1.41 mm |
| Bottom Bracket Height | 360 mm | 360 mm | 360 mm |
| Stack | 600 mm | 609 mm | 619 mm |
| Reach | 390 mm | 418 mm | 440 mm |
| Top Tube Length | 573 mm | 603 mm | 628 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 440 mm | 480 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 478 mm | 478 mm | 478 mm |
| Bottom Bracket Drop | -5 mm | -5 mm | -5 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Overvolt AM 700+ is part of the Lapierre E Overvolt model. There are 146 e-bikes that carry this model name. Take a sneak peek at all Lapierre E Overvolt e-bikes models from 2018, by clicking here.
Model range prices
Lapierre OVERVOLT TREKKING 100 2018 is the cheapest e-bike model and costs 1698$. Lapierre OVERVOLT AM 829i SHIMANO 2018 is the most expensive one and costs 6901$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Enduro e-bikes average price
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Enduro e-bikes average weight
The average weight for Enduro e-bikes is 23.42 kg (51.63 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 22.8 kg (50.27 lbs), Lapierre e-bike is slightly lighter than average. In other words, this model is 2.72% lighter than the average Enduro e-bike.
Overview of components
Fork
Lapierre Overvolt AM 700+ 2018 e-bike is equipped with the RockShox Revelation RC fork, and has 150mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this e-bike is RockShox Deluxe RT DebonAir, with a travel distance of 150mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
As for the wheels, Lapierre Overvolt AM 700+ 2018, has a 27.5″ aluminum model. These wheels will provide you with more control over the e-bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Lapierre Overvolt AM 700+ is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Overvolt AM 700+ comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
