Lauf True Grit – Ekar 2022
2022 Road
Estimate price |
4,840$
Weight | 8.3 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Travel Front 30mm -
Fork Lauf Grit SL
-
Groupset Ekar -
Suspension Hardtail -
Drivetrain 1 × 13 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 175cm
MD
172cm - 183cm
LG
180cm - 191cm
XL
188cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Lauf IRM* carbon frame, 12x142mm thru-axle
Suspension Fork
Lauf Grit SL Carbon, 15x100mm thru-axle, size tuned stiffness
Drivetrain
Rear Derailleur
Campagnolo Ekar 13sp
Front Derailleur
Lauf Bottle Opener
Shift Levers
Campagnolo Ekar Ergopower
Cassette
Campagnolo Ekar 13 speed, 9-42t
Crank
Campagnolo Ekar Carbon 38t
Bottom Bracket
Campagnolo Ekar Pro-Tech
Chain
Campagnolo Ekar C13
Wheels
Rims
e*thirteen XCX Race Carbon (6-bolt, N3W freehub, tubeless ready)
Tires
Maxxis Rambler 40c (120tpi)
Brakes
Brakes
Campagnolo Ekar Flat mount Hydraulic (160mm rotor front/left and rear/right)
Cockpit
Stem
FSA V-Drive, 6°
Handlebar
Lauf Smoothie (XS/S: 40 M: 42 L/XL: 44)
Headset
FSA Orbit, IS 42/52 (45°lower)
Seat
Saddle
Fizik Aliante R5
Seatpost
FSA SL-K 27.2mm, Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.4 mm | 1.43 mm | 1.46 mm | 1.5 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 593 mm | 603 mm | 623 mm | 645 mm | 667 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 74 mm | 73 mm | 74 mm | 74 mm | 72 mm |
| Stack | 515 mm | 529 mm | 556 mm | 585 mm | 615 mm |
| Reach | 373 mm | 378 mm | 389 mm | 400 mm | 411 mm |
| Top Tube Length | 537 mm | 546 mm | 566 mm | 586 mm | 606 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 520 mm | 542 mm | 565 mm | 595 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 90 mm | 105 mm | 133 mm | 164 mm | 196 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1004 mm | 1015 mm | 1035 mm | 1056 mm | 1079 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 726 mm | 758 mm | 781 mm | 805 mm | 835 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 172 cm | 180 cm | 188 cm |
| Rider Max Height | 166 cm | 175 cm | 183 cm | 191 cm | 199 cm |
Model Overview
True Grit – Ekar belongs to the Lauf True model. There are 17 bikes that carry this model name. Take a sneak peek at all Lauf True bikes models from 2022, by clicking here.
Model range prices
Lauf True Grit – Weekend Warrior 2022 is the most economical model, with a starting price of 2676$. Lauf True Grit – Ultimate 2022 on the other hand costs 6105$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2022 for 4481$. Doing a quick comparison, we notice that True Grit – Ekar price is 82.01% higher than the average cost of a Gravel bike.
Gravel bikes average weight
If we make a quick analysis of the average weight of a Gravel bike, we get 8.13 kg (17.92 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
slightly heavier than average, True Grit – Ekar has a weight of 8.3 kg (18.3 lbs). In other words, this model is 2.09% heavier than the average Gravel bike.
Overview of components
Fork
This bike has the Lauf Grit SL fork installed. The fork’s travel is 30mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Lauf True Grit – Ekar 2022, has a 700c carbon model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Lauf True Grit – Ekar has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Lauf True Grit – Ekar bike has 5 sizes, in the range of 156 cm – 199 cm (5.12 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
