Lauf True Grit Race AXS 2019
2019 Road
Estimate price |
5,490$
Weight | 8.3 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Fork Lauf Grit SL -
Groupset X01 Eagle AXS, Force eTAP -
Suspension Hardtail -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 175cm
MD
172cm - 183cm
LG
180cm - 191cm
XL
188cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Lauf True Grit Carbon, 12x142mm through-axle
Suspension Fork
Lauf Grit SL Carbon, 15x100mm through-axle
Drivetrain
Rear Derailleur
SRAM Eagle X01 AXS
Front Derailleur
Lauf Bottle Opener
Shift Levers
SRAM Force 1 AXS
Cassette
SRAM Eagle GX 10-50
Crank
SRAM Force 1 DUB, 42t
Bottom Bracket
SRAM DUB BSA Road 68mm
Chain
SRAM Eagle NX 12sp
Wheels
Rims
DT Swiss XR1501 (6-bolt, xD freehub, tubeless ready)
Tires
Maxxis Rambler 40c (120tpi)
Brakes
Brakes
SRAM Force 1 Flat mount Hydraulic (160mm rotor front and rear)
Cockpit
Stem
FSA V-Drive, 6°
Handlebar
Lauf Smoothie (XS,S: 400, M: 420, L,XL: 440)
Headset
FSA Orbit, IS 42/52 (45°lower)
Seat
Saddle
Ritchey Superlogic Streem
Seatpost
FSA SL-K 27.2mm, Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.4 mm | 1.43 mm | 1.46 mm | 1.5 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 593 mm | 603 mm | 623 mm | 645 mm | 667 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 74 mm | 73 mm | 74 mm | 74 mm | 72 mm |
| Stack | 515 mm | 529 mm | 556 mm | 585 mm | 615 mm |
| Reach | 373 mm | 378 mm | 389 mm | 400 mm | 411 mm |
| Top Tube Length | 537 mm | 546 mm | 566 mm | 586 mm | 606 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 520 mm | 542 mm | 565 mm | 595 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 90 mm | 105 mm | 133 mm | 164 mm | 196 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1004 mm | 1015 mm | 1035 mm | 1056 mm | 1079 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 726 mm | 758 mm | 781 mm | 805 mm | 835 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 172 cm | 180 cm | 188 cm |
| Rider Max Height | 166 cm | 175 cm | 183 cm | 191 cm | 199 cm |
Model Overview
True Grit Race AXS completes the Lauf True model. 17 bikes variations carry this model name so far. Take a sneak peek at all Lauf True bikes models from 2019, by clicking here.
Model range prices
Lauf True Grit Weekend Warrior 2019 is the most affordable bike of this model and has a price of 3690$. On the other hand, Lauf True Grit Ultimate 2019, is the most expensive and costs 10490$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2019 and its price was 5490$. If we compare this with the average Gravel bike cost we notice that the price is 122.99% more expensive.
Average weight for Gravel bikes
If we make a quick analysis of the average weight of a Gravel bike, we get 8.13 kg (17.92 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 8.3 kg (18.3 lbs), Lauf bike is slightly heavier than average. In conclusion, the average Gravel bike weighs 2.09% less than True Grit Race AXS.
True Grit Race AXS components
Fork
This bike has the Lauf Grit SL fork installed. The fork’s travel is mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the True Grit Race AXS model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 199 cm (5.12 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
