Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
titanium
Suspension Fork
Litespeed Carbon Tapered Fork
Drivetrain
Rear Derailleur
Ultegra
Front Derailleur
Ultegra
Shift Levers
Ultegra
Cassette
R7000 11-30
Crank
Ultegra R8000 50/34
Bottom Bracket
FSA
Chain
Shimano HG701
Wheels
Rims
Optimized for clearance on up to 25mm tires/130mm axle spacing (most tire/rim combinations)
Tires
Continental Ultrasport3 25c Folding
Brakes
Brakes
Ultegra
Cockpit
Stem
FSA Energy
Handlebar
FSA Energy Compact
Headset
Cane Creek 40 Series
Seat
Saddle
Prologo Scratch 2 Pas T2.0 134
Seatpost
FSA SLK Carbon 20mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.47 mm | 1.52 mm | 1.55 mm | 1.59 mm | 1.64 mm |
| Bottom Bracket Height | 268 mm | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 566 mm | 568 mm | 574 mm | 590 mm | 600 mm | 607 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 66 mm | 62 mm | 58 mm | 59 mm | 60 mm | 65 mm |
| Stack | 517 mm | 533 mm | 553 mm | 577 mm | 600 mm | 629 mm |
| Reach | 357 mm | 362 mm | 365 mm | 373 mm | 378 mm | 383 mm |
| Top Tube Length | 507 mm | 517 mm | 532 mm | 552 mm | 562 mm | 582 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 475 mm | 495 mm | 515 mm | 535 mm | 555 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 110 mm | 125 mm | 145 mm | 170 mm | 195 mm | 220 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 964 mm | 969 mm | 975 mm | 989 mm | 1000 mm | 1009 mm |
| Bottom Bracket Drop | 68 mm | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm |
| Standover Height | 712 mm | 722 mm | 739 mm | 759 mm | 781 mm | 806 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
Model Overview
T5 — Ultegra is a Litespeed T5 model. 15 bikes variations carry this model name so far. You can easily view all of the Litespeed T5 bikes models from 2022, here.
Model range prices
The most economical model, the Litespeed T5 — Shimano 105 2022 has a starting price of 3095$. Litespeed T5 — Ultegra Di2 2022 on the other hand is the most expensive at 4395$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Endurance bikes
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2022 for 3895$. Comparing this to the average Endurance bike price, we see that the price is 66.03% higher.
Overview of components
Fork material
T5 — Ultegra has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The T5 — Ultegra 2022 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Litespeed T5 — Ultegra is equipped with Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
T5 — Ultegra comes in 6 sizes, that range from 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
