Litespeed Ultimate Disc — SRAM Red AXS 2020
2020 Road
Estimate price |
7,439$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 700c -
Groupset RED eTAP -
Suspension Rigid -
Drivetrain Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
titanium
Suspension Fork
Litespeed Carbon
Drivetrain
Rear Derailleur
SRAM Red AXS
Front Derailleur
SRAM Red AXS
Shift Levers
SRAM Red AXS
Cassette
SRAM Red AXS
Crank
SRAM Red AXS
Bottom Bracket
SRAM PF30
Chain
SRAM Red AXS
Wheels
Rims
Optimized for clearance on up to 30mm tires (most tire/rim combinations)
Tires
Continental GP5000 28c
Brakes
Brakes
SRAM Red Hydraulic Disc
Disk Rotors
Centerline 2-Piece
Cockpit
Stem
Easton EA90
Handlebar
Easton EC90 Aero
Headset
Chris King InSet 7 Matte Black
Seat
Saddle
Prologo Scratch 2 PAS Tirox
Seatpost
Litespeed Titanium
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.41 mm | 1.43 mm | 1.44 mm | 1.49 mm | 1.54 mm |
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm | 268 mm |
| Front Center | 566 mm | 571 mm | 576 mm | 592 mm | 605 mm | 619 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 61 mm | 59 mm | 56 mm | 56 mm | 56 mm | 57 mm |
| Stack | 519 mm | 534 mm | 549 mm | 569 mm | 594 mm | 624 mm |
| Reach | 374 mm | 379 mm | 384 mm | 394 mm | 399 mm | 404 mm |
| Top Tube Length | 519 mm | 529 mm | 544 mm | 564 mm | 579 mm | 594 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 455 mm | 475 mm | 495 mm | 515 mm | 535 mm | 555 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 101 mm | 115 mm | 129 mm | 150 mm | 176 mm | 207 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 975 mm | 980 mm | 985 mm | 1001 mm | 1014 mm | 1028 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm | 68 mm |
| Standover Height | 720 mm | 738 mm | 756 mm | 776 mm | 799 mm | 824 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
Model Overview
Ultimate Disc — SRAM Red AXS is a Litespeed Ultimate model. Litespeed launched 55 bikes of this model so far. You can easily view all of the Litespeed Ultimate bikes models from 2020, here.
Model range prices
Litespeed Ultimate — Shimano 105 2020 is the most economical model, with a starting price of 2999$. Litespeed Ultimate Gravel — SRAM Red eTap 2020 on the other hand costs 7699$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Race bikes
If you want an acceptable Race bike you should know that the average price is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2020 and its price was 7439$. In conclusion, this bike price is 122.06% higher than the price of the average Race bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
As for the wheels, Litespeed Ultimate Disc — SRAM Red AXS 2020, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Ultimate Disc — SRAM Red AXS comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 6 sizes. They vary from 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
