Litespeed Ultimate Gravel — Ultegra 2020
2020 Road
Estimate price |
5,499$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 700c / 650b -
Groupset Ultegra, Praxis -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 173cm
SM
162cm - 173cm
MD
169cm - 180cm
MD
169cm - 180cm
MD/LG
175cm - 186cm
MD/LG
175cm - 186cm
LG
180cm - 192cm
LG
180cm - 192cm
XL
188cm - 199cm
XL
188cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
titanium
Suspension Fork
Litespeed Carbon
Drivetrain
Rear Derailleur
Ultegra
Front Derailleur
Ultegra
Shift Levers
Ultegra
Cassette
Ultegra 11-34
Crank
Praxis Zayante Alloy 48/32
Bottom Bracket
FSA PF30
Chain
Shimano HG701
Wheels
Rims
Stan's Grail MK3 700C
Tires
700C Tires - Panaracer Gravel King SK 700x38c Tubeless, 650B Tires - Panaracer Gravel King SK 650Bx1.9 Tubeless
Brakes
Brakes
Ultegra
Disk Rotors
Shimano RT81 160mm
Cockpit
Stem
Easton EA70 31.8
Handlebar
Easton EA70AX
Headset
Cane Creek 40 Series
Seat
Saddle
WTB Volt Pro
Seatpost
Race Face Next Carbon Zero Setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | MD | MD | MD/LG | MD/LG | LG | LG | XL | XL |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.48 mm | 1.5 mm | 1.5 mm | 1.51 mm | 1.51 mm | 1.55 mm | 1.55 mm | 1.61 mm | 1.61 mm |
| Bottom Bracket Height | 275 mm | mm | 278 mm | mm | 278 mm | mm | 281 mm | mm | 281 mm | mm |
| Front Center | 587 mm | 587 mm | 592 mm | 592 mm | 609 mm | 609 mm | 622 mm | 622 mm | 637 mm | 637 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 64 mm | 58 mm | 61 mm | 55 mm | 61 mm | 55 mm | 61 mm | 55 mm | 61 mm | 55 mm |
| Stack | 557 mm | 557 mm | 572 mm | 572 mm | 592 mm | 592 mm | 617 mm | 617 mm | 647 mm | 647 mm |
| Reach | 377 mm | 377 mm | 382 mm | 382 mm | 392 mm | 392 mm | 397 mm | 397 mm | 402 mm | 402 mm |
| Top Tube Length | 535 mm | 535 mm | 549 mm | 549 mm | 565 mm | 565 mm | 584 mm | 584 mm | 598 mm | 598 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 475 mm | 475 mm | 495 mm | 495 mm | 515 mm | 515 mm | 535 mm | 535 mm | 555 mm | 555 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 106 mm | 106 mm | 123 mm | 123 mm | 144 mm | 144 mm | 173 mm | 173 mm | 205 mm | 205 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1008 mm | 1008 mm | 1014 mm | 1014 mm | 1031 mm | 1031 mm | 1045 mm | 1045 mm | 1060 mm | 1060 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 71 mm | 71 mm | 71 mm | 71 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 762 mm | 762 mm | 782 mm | 782 mm | 797 mm | 797 mm | 823 mm | 823 mm | 851 mm | 851 mm |
| Wheels | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 |
| Rider Min Height | 162 cm | 162 cm | 169 cm | 169 cm | 175 cm | 175 cm | 180 cm | 180 cm | 188 cm | 188 cm |
| Rider Max Height | 173 cm | 173 cm | 180 cm | 180 cm | 186 cm | 186 cm | 192 cm | 192 cm | 199 cm | 199 cm |
Model Overview
Ultimate Gravel — Ultegra is part of the Litespeed Ultimate model. Litespeed launched 55 bikes of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Litespeed Ultimate — Shimano 105 2020 is the most economical model, with a starting price of 2999$. Litespeed Ultimate Gravel — SRAM Red eTap 2020 on the other hand costs 7699$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2020 for 5499$. Doing a quick comparison, we notice that Ultimate Gravel — Ultegra price is 123.35% more expensive than the average cost of a Gravel bike.
Ultimate Gravel — Ultegra components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The wheels on Ultimate Gravel — Ultegra are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Ultimate Gravel — Ultegra has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 10 sizes available for this model. Rider height can be anywhere between 162 cm – 199 cm (5.31 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
