Litespeed Ultimate — Ultegra 2020
2020 Road
Estimate price |
3,599$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
titanium
Suspension Fork
Litespeed Carbon Tapered Fork
Drivetrain
Rear Derailleur
Ultegra
Front Derailleur
Ultegra
Shift Levers
Ultegra
Cassette
Ultegra 11-30
Crank
Ultegra 50/34
Bottom Bracket
Praxis
Chain
Shimano HG701
Wheels
Rims
Optimized for clearance on up to25mm tires (most tire/rim combinations)
Tires
Continental Ultra Sport II Folding 25c
Brakes
Brakes
Ultegra
Cockpit
Stem
Easton EA70 31.8
Handlebar
Easton EA70
Headset
Cane Creek 40 Series
Seat
Saddle
Prologo Scratch 2.0
Seatpost
Race Face Next Carbon Zero Setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.41 mm | 1.43 mm | 1.44 mm | 1.49 mm | 1.54 mm |
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm | 268 mm |
| Front Center | 566 mm | 571 mm | 576 mm | 592 mm | 605 mm | 620 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 61 mm | 59 mm | 56 mm | 55 mm | 55 mm | 55 mm |
| Stack | 519 mm | 534 mm | 549 mm | 569 mm | 594 mm | 624 mm |
| Reach | 374 mm | 379 mm | 384 mm | 394 mm | 399 mm | 404 mm |
| Top Tube Length | 517 mm | 526 mm | 545 mm | 561 mm | 579 mm | 594 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 455 mm | 475 mm | 495 mm | 515 mm | 535 mm | 555 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 101 mm | 115 mm | 128 mm | 149 mm | 176 mm | 207 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 966 mm | 971 mm | 976 mm | 993 mm | 1005 mm | 1021 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm | 68 mm |
| Standover Height | 717 mm | 735 mm | 752 mm | 774 mm | 796 mm | 826 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
Model Overview
Ultimate — Ultegra completes the Litespeed Ultimate model. There are 55 bikes that carry this model name. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Litespeed Ultimate — Shimano 105 2020 is the most economical model, with a starting price of 2999$. Litespeed Ultimate Gravel — Dura-Ace Di2 2020 on the other hand costs 7699$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Race bikes
Our math shows that the average cost of a dependable Race bike is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Litespeed Ultimate — Ultegra price was 3599$. Comparing this to the average Race bike price, we see that the price is 7.43% more expensive.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The wheels on Ultimate — Ultegra are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Ultimate — Ultegra has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Ultimate — Ultegra comes in 6 sizes, that range from 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
