Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Alivio, Acera -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
148cm - 163cm
SM
158cm - 169cm
MD
164cm - 175cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum
Suspension Fork
Advanced-Grade Composite, alloy steerer, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
Shimano Acera
Shift Levers
Shimano Altus
Cassette
Shimano HG200, 9-speed, 11x36
Crank
Shimano Altus, 30/46 with chainguard
Bottom Bracket
Shimano SM-BB52
Chain
KMC X9
Pedals
Giant Urban Fitness
Wheels
Front Hub
Giant GX wheelset, QR, 32h
Rear Hub
Giant GX wheelset, QR, 32h
Rims
Giant GX Disc wheelset
Spokes
stainless, 14g
Tires
Giant CrossCut Metro, 700x38c
Brakes
Brakes
Tektro R280 hydraulic, 160mm
Brake Levers
Tektro, hydraulic
Cockpit
Stem
Giant Sport
Handlebar
Giant Sport, alloy
Seat
Saddle
Liv Sport Comfort
Seatpost
Giant Sport, 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.5 mm | 1.52 mm |
| Front Center | 623 mm | 629 mm | 633 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 75.1 mm | 72 mm | 68.7 mm |
| Stack | 570 mm | 587 mm | 603 mm |
| Reach | 387 mm | 392 mm | 396 mm |
| Top Tube Length | 549 mm | 564 mm | 579 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 370 mm | 420 mm | 460 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° |
| Head Tube Length | 145 mm | 160 mm | 175 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1071 mm | 1077 mm | 1081 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 687 mm | 723 mm | 753 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 148 cm | 158 cm | 164 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm |
Model Overview
Alight 1 DD Disc belongs to the Liv Alight model. Liv launched 60 bikes of this model so far. Take a sneak peek at all Liv Alight bikes models from 2021, by clicking here.
Model range prices
Liv Alight 24 2021 is the most affordable bike of this model and has a price of 470$. On the other hand, Liv Alight 1 Disc 2021, is the most expensive and costs 976$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Commuter bikes average price
According to our math, the average price for a trustworthy Commuter bike is 762$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2021 for 737$. In conclusion, this bike price is 3.39% smaller than the price of the average Commuter bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on Alight 1 DD Disc are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Alight 1 DD Disc comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Liv Alight 1 DD Disc bike has 3 sizes, in the range of 148 cm – 175 cm (4.86 ft – 5.74 ft). In conclusion, it won’t take much to find one that’s right for you.
