Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset Tourney, Altus -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
XS
148cm - 163cm
SM
158cm - 169cm
MD
164cm - 175cm
LG
170cm - 183cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum
Suspension Fork
steel/alloy
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney
Front Derailleur
Shimano Altus
Shift Levers
Shimano Tourney, 3x7
Cassette
Shimano MF-TZ500, 14x34
Crank
ProWheel TY-CQ99, 28/38/48 XS:165mm, S:165mm, M:170mm, L:172.5mm
Bottom Bracket
cartridge
Chain
KMC Z7
Pedals
platform
Wheels
Front Hub
alloy, loose ball bearing
Rear Hub
alloy, loose ball bearing
Rims
Giant GX06 alloy
Spokes
stainless, 14g
Tires
Giant S-X3, puncture protect, 700x38c
Brakes
Brakes
Tektro TK837, alloy, linear pull
Brake Levers
Shimano EF41
Cockpit
Stem
Giant Sport, 25.4mm XS:60mm, S:60mm, M:75mm, L:90mm
Handlebar
Giant Sport XC, 25.4mm XS:60cm, S:60cm, M:64cm, L:64cm
Grips
Ergo Max XS: 31mm, S:31mm, M:31mm, L:34mm
Seat
Saddle
Sport Saddle
Seatpost
alloy, 27.2mm XS:300mm, S:300mm, M:300mm, L:300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.59 mm | 1.65 mm | 1.68 mm |
| Front Center | 598 mm | 609 mm | 609 mm | 618 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 75.6 mm | 72.3 mm | 69 mm | 69.2 mm |
| Stack | 572 mm | 589 mm | 610 mm | 628 mm |
| Reach | 361 mm | 371 mm | 369 mm | 373 mm |
| Top Tube Length | 549 mm | 564 mm | 579 mm | 594 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 370 mm | 420 mm | 460 mm | 500 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 145 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1039 mm | 1050 mm | 1050 mm | 1060 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm | 62 mm |
| Standover Height | 687 mm | 723 mm | 753 mm | 783 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 148 cm | 158 cm | 164 cm | 170 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 183 cm |
Model Overview
Alight 3 completes the Liv Alight model. Liv released 60 bikes variations of this model so far. You can easily view all of the Liv Alight bikes models from 2022, here.
Model range prices
Liv Alight 24 2022 is the most affordable bike of this model and has a price of 337$. On the other hand, Liv Alight DD Disc 1 2022, is the most expensive and costs 930$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Commuter bikes average price
According to our calculations, the average cost of a Commuter bike that is reliable is 762$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Liv released this model in 2022, its price was 560$. If we compare this with the average Commuter bike cost we notice that the price is 36.07% lower.
Alight 3 components
Fork material
Alight 3 has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When leaving the production line, the Alight 3 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Alight 3 comes with Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
This bike is available in 4 sizes. They vary from 148 cm – 183 cm (4.86 ft – 6 ft). In short, you can easily find one that suits you.
