Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset Tourney, Altus -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
148cm - 163cm
SM
158cm - 169cm
MD
164cm - 175cm
LG
170cm - 183cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum, disc
Suspension Fork
alloy, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney
Front Derailleur
Shimano Altus
Shift Levers
Shimano Tourney, 3x7
Cassette
Shimano MF-TZ500, 14x34
Crank
ProWheel TY-CQ99, 28/38/48 XS:165mm, S:165mm, M:170mm, L:172.5mm
Bottom Bracket
cartridge
Chain
KMC Z7
Pedals
platform
Wheels
Front Hub
Giant GX Disc wheelset
Rear Hub
Giant GX Disc wheelset
Rims
Giant GX Disc wheelset
Spokes
Giant GX Disc wheelset
Tires
Giant S-X3, puncture protect, 700x38c
Brakes
Brakes
Tektro TKB-172 mechanical [F]160mm, [R]160mm
Brake Levers
Tektro mechanical
Cockpit
Stem
Giant Sport, 25.4mm XS:80mm, S:80mm, M:90mm, L:100mm
Handlebar
Giant Sport XC, 25.4mm XS:60cm, S:60cm, M:64cm, L:64cm
Grips
Dynamic Comfort XS: 31mm, S:31mm, M:31mm, L:34mm
Seat
Saddle
Liv Sport Comfort
Seatpost
Giant D-Fuse, alloy XS:350mm, S:350mm, M:350mm, L:350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.51 mm | 1.5 mm | 1.48 mm |
| Front Center | 607 mm | 617 mm | 627 mm | 647 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 78.2 mm | 74.8 mm | 71.4 mm | 71.4 mm |
| Stack | 558 mm | 579 mm | 591 mm | 605 mm |
| Reach | 375 mm | 384 mm | 395 mm | 410 mm |
| Top Tube Length | 539 mm | 554 mm | 574 mm | 594 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 370 mm | 420 mm | 460 mm | 500 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 130 mm | 150 mm | 160 mm | 175 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1048 mm | 1059 mm | 1069 mm | 1089 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm | 62 mm |
| Standover Height | 595 mm | 594 mm | 595 mm | 591 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 148 cm | 158 cm | 164 cm | 170 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 183 cm |
Model Overview
Alight DD Disc 3 belongs to the Liv Alight model. There are 60 bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Liv Alight 24 2022 is the most economical model, with a starting price of 337$. Liv Alight DD Disc 1 2022 on the other hand costs 930$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Commuter bikes average price
If you want an acceptable Commuter bike you should know that the average price is 762$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Liv released this model in 2022, its price was 556$. Doing a quick comparison, we notice that Alight DD Disc 3 price is 37.05% lower than the average cost of a Commuter bike.
Overview of components
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
When it comes to wheels, the Alight DD Disc 3 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 148 cm – 183 cm (4.86 ft – 6 ft). In conclusion, finding one for you shouldn’t be a problem.
